Sida 1/83

Air Handling Unit

D-EOMAH00006-20EN

Operation Manual

Operating Manual

Air Handling Unit

Application Software name: Airstream

D-EOMAH00006-20EN

Operation Manual

Air Handling Unit


Operation Manual


Air Handling Unit
D-EOMAH00006-20EN

Table of Contents
 Revision History..................................................................................................................... 4
 Air Handling Unit Safety Information...................................................................................... 5
 Introduction .......................................................................................................................... 6
 User interface........................................................................................................................ 8
1  Controller POL687/638 Interfaces ...................................................................................................................... 8
2  External Human Machine Interfaces .................................................................................................................. 9
2.1  6-Button LCD HMI (POL871) ................................................................................................................................................ 9
2.2  Push & Roll key HMI (POL895) ............................................................................................................................................. 9
3  WEB-Human Machine Interface ....................................................................................................................... 11
4  Communication Modules .................................................................................................................................. 15
4.1  Modbus module installation .............................................................................................................................................. 16
4.2  BACnet IP module installation ........................................................................................................................................... 16
5  Basic Control System Diagnostic ....................................................................................................................... 16
 Control Functions ................................................................................................................ 19
1  Air Quality Control Function ............................................................................................................................. 20
2  Humidity Control Function ................................................................................................................................ 20
3  Summer/Winter mode changeover functions .................................................................................................. 21
 Main Menu screen .............................................................................................................. 22
 Control Source .................................................................................................................... 24
 Actual Mode........................................................................................................................ 25
 Unit State ............................................................................................................................ 26
 Active Setpoint .................................................................................................................... 28
 Local Switch ........................................................................................................................ 29
 Summer/Winter state .......................................................................................................... 30
 Setpoints ............................................................................................................................. 32
 I/O Overview ....................................................................................................................... 35
 Time Scheduler.................................................................................................................... 36
1  Day Scheduler.................................................................................................................................................... 37
2  Calendar exception and Calendar fix off........................................................................................................... 38
 Status/Settings .................................................................................................................... 40
1  Temperature Control ........................................................................................................................................ 41
2  Air Quality Control............................................................................................................................................. 42
3  Humidity Control ............................................................................................................................................... 43
4  Fans Control ...................................................................................................................................................... 44
4.1  Fast Heating/Cooling .......................................................................................................................................................... 48
5  Dampers Control ............................................................................................................................................... 49
6  Heat Recovery Control ...................................................................................................................................... 50
7  Cooling Coil Control........................................................................................................................................... 50
8  Heating Coil Control .......................................................................................................................................... 51
9  Pumps Control ................................................................................................................................................... 53
