Installation and operation manual
1
EKSOLHTBV1
Solar kit for air to water heat pump system
4PW67028-1A – 08.2011
CONTENTS Page
1. Definitions.................................................................................. 1
1.1. Meaning of warnings and symbols................................................. 1
1.2. Meaning of used terms .................................................................. 2
2. General safety precautions........................................................ 2
3. Introduction................................................................................ 3
3.1. General information........................................................................ 3
3.2. Scope of this manual ..................................................................... 3
3.3. Model identification ........................................................................ 3
4. Accessories ............................................................................... 3
5. Overview of the solar kit ............................................................ 4
5.1. Main components........................................................................... 4
5.2. Safety functions.............................................................................. 4
Domestic hot water tank tank thermal cut out................................ 4
Piping thermal cut out .................................................................... 4
6. General system setup and operation......................................... 4
7. Installation of the solar kit .......................................................... 5
7.1. Selecting an installation location.................................................... 5
7.2. Dimensions and service space ...................................................... 5
7.3. Inspecting, handling and unpacking the unit.................................. 5
7.4. Installation guidelines..................................................................... 5
7.5. Installing the solar kit ..................................................................... 5
Procedure ...................................................................................... 5
Charging water............................................................................... 7
7.6. Field wiring..................................................................................... 7
Overview ........................................................................................ 7
Installing the EKRP1HB in the unit ................................................ 8
Connecting the temperature sensors............................................. 8
Connecting the solar pump station controller, solar pump
station, indoor unit, domestic hot water tank and solar kit ............. 8
8. Installation of solenoid valve kit EKUHT2WB .......................... 10
8.1. Last steps of mounting the kit inside the unit ............................... 10
8.2. Guiding the wiring towards the switch box ................................... 10
8.3. Last step of connecting the wiring................................................ 10
9. Start up.................................................................................... 11
9.1. Commissioning the system before initial start up......................... 11
9.2. Checklist for proper functioning.................................................... 11
10. Operating instructions.............................................................. 11
10.1. Configuring your system .............................................................. 11
Use of schedule timers ................................................................ 11
Setting of domestic hot water tank temperature........................... 12
Setting of the solar priority parameter.......................................... 12
11. Troubleshooting and servicing ................................................. 13
11.1. General guidelines ....................................................................... 13
11.2. General symptoms....................................................................... 13
11.3. Error codes .................................................................................. 13
12. Disposal requirements............................................................. 13
13. Technical specifications ........................................................... 13
Annex ...................................................................................... 14
Decision flow of heating the domestic
water by heat pump or by solar kit ............................................... 14
The English text is the original instruction. Other languages are
translations of the original instructions.
1. DEFINITIONS
1.1. Meaning of warnings and symbols
Warnings in this manual are classified according to their severity and
probability of occurrence.
Some types of danger are represented by special symbols:
EKSOLHTBV1
Solar kit for air to water heat pump system
Installation and
operation manual
CAREFULLY READ THESE INSTRUCTIONS BEFORE
INSTALLATION. THEY WILL TELL YOU HOW TO
INSTALL, HOW TO CONFIGURE AND HOW TO USE THE
EKSOLHTB SOLAR KIT PROPERLY.
KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE
REFERENCE.
THE UNIT DESCRIBED IN THIS MANUAL IS DESIGNED
FOR INDOOR INSTALLATION ONLY AND FOR AMBIENT
TEMPERATURES RANGING 0°C~35°C.
DANGER
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also
be used to alert against unsafe practices.
NOTICE
Indicates situations that may result in equipment or
property-damage accidents only.
INFORMATION
This symbol identifies useful tips or additional information.
Electric current.
Danger of burning and scalding.
