DLEDW‐300,‐310,‐330‐Installationinstructions
Important information
Caution
This product must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product and the hazards
involved. We recommend you use a licenced electrician.
This product is designed to be wall mounted and is suitable for use outdoors in wet locations. Follow detailed instructions for wet location installation.
To reduce the risk of fire, electrical shock, or injury to persons, turn off power before installation or maintenance.
Do not use luminaire with a damaged lens, body or cable.
Installation into existing drywall / plywood / OSB.
This product is designed to be installed after wall sheeting material has been applied. Hole must have minimum depth of 4” (102mm). This product is supplied with its own
plastic UL approved housing. Use appropriate ½” (12.7mm) strain relief (not supplied).
Cutting hole:
- Find exact locations for wall studs. Hole must be cut a minimum of ½” (13mm) from the outside of the stud. Make sure that there are no wires or pipes in the
location behind your hole.
Preparation to install fixture:
-Your wall light comes fully assembled in the package. Separate all the parts as shown:
Proceed to install fixture:
-Make sure the electrical wire is easily accessible behind the hole in the wall
-Install mounting bracket
-Find wire behind the wall. Pull through hole. Remove protective outer covering to 8” (200mm). Attach UL approved strain relief to wire (not supplied). Feed wire
into plastic housing, then screw housing onto strain relief. Note position of protruding screw from strain relief.
-Install plastic housing into mounting bracket already installed in wall. Use 3 screws provided to attach firmly.
LR1331
3.3WLED
120V60Hz
Samsung
2700K
CRI80+
Produktspecifikationer
| Varumärke: | Dainolite |
| Kategori: | Lampa |
| Modell: | DLEDW-300 |
