Mini-Split System

Evaporator

Indoor Unit ConfigurationOutdoor Unit Configuration

Connection

Fan

System

Pipe

Connection

Stop Valve

Tube

Fin

Indoor Unit Weight （Net /Gross Kg - 7.0/9.0 - 8.0/10.0 - 9.0/11.0 - 13/16 - ）Lbs 15.4/19.8 17.6/22.0 19.8/24.2 28.6/35.2

Cooling capacity BTU/H 9000 12000 18000 22000 32000

Rated Power Consumption W 921 1100 1785 2308 2800

Rated Running Current A 4.19 5.00 8.05 10.4 12.7

Max. Input Power W 1500 1300 2250 2870 3200

Max. Input Current A 6.5 7 11.5 14.5 16.5

Power supply Source V/Ph/Hz 208-230V/60HZ 208-230V/60HZ 208-230V/60HZ 208-230V/60HZ 208-230V/60HZ

Refrigerant -- R410A R410A R410A R410A R410A

Refrigerant Charged g 580 600 800 1040 1200

Max. Discharge Pressure Mpa 4.15 4.15 4.15 4.15 4.15

Max. Suction Pressure Mpa 1.15 1.15 1.15 1.15 1.15

Air Flow Volume m3/h 420 490 580 1050 1100

Noise Level dB（A) 39 42 47 49 49

Noise Level dB（A) 51 50 55 57 58

14/17 - 30.8/37.4

Outdoor Unit Weight (Net /Gross) Kg - 20/23 - 24/27 - 32/36 - 38/43 - 45/50 - Lbs 44.0/50.7 52.9/59.5 70.5/79.3 83.7/94.7 99.2/110.2

20’ / 40’ / 40’ HQ Sets 122 / 245 / 303 122 / 245 / 295 107 / 215 / 250 72 /145 / 180 68 /136 / 160

Multi-bend -- 2 3 3 4 4

Model -- DX09E426-13 DX12E426-13 DX18E426-13 DX24E426-13 DX32E426-13

Model DX09C426-13 DX12C426-13 DX18C426-13 DX24C426-13 DX32C426-13--

Rows Row 2 2 2 2 2

Material -- Inner-Grooved Copper Inner-Grooved Copper Inner-Grooved Copper Inner-Grooved Copper Inner-Grooved Copper

Diameter Inches ĭ ĭ ĭ ĭ ĭ

Product Specification Sheet Model DX0913 DX1213 DX1813 DX2413 DX3213

Material -- Hydrophilic Aluminium Foil Hydrophilic Aluminium Foil Hydrophilic Aluminium Foil Hydrophilic Aluminium Foil Hydrophilic Aluminium Foil

Fin Type -- Window Window Window Window Window

Fan

Cross-Flow FanType -- Cross-Flow Fan Through-Flow Fan Through-Flow Fan Cross-Flow Fan

Material -- ABS AS ABS ABS AS

Net Dimension(Width×Depth×Height) Inches îî îî îî îî îî

Packing Dimension(Width×Depth×Height) Inches îî îî îî îî îî

Diameter × Length Inches ĭî ĭî ĭî ĭî ĭî

Dimensions

-- Copper/Aluminum Copper/Aluminum Copper/Aluminum Copper/Aluminum Copper/AluminumMaterial

Liquid tube Diameter Inches ĭ ĭ ĭ ĭ ĭ

Gas tube Diameter Inches ĭ ĭ ĭ ĭ ĭ

Liquid Valve -- Dg4 Dg4 Dg4 Dg8 Dg8

Gas Valve -- Dg8 Dg8 Dg10 Dg13 Dg13

Fan

System

Fan

--Type Axial-Flow Fan Axial-Flow Fan Axial-Flow Fan Axial-Flow Fan Axial-Flow Fan

Blade Material -- ABS AS AS ABS AS

Fan Motor Model -- YDK20-6C-60 YDK28-6-60 YDK40-6-60 YDK66-6A-60 YDK69-6A-60

Air circulation m /h

31200 1780 2000 2300 3200

Condenser

Capillary A

Casing

RowRows 1 1 2 2 2

Bended or Flat -- Bended Bended Bended Bended Bended

--Material Copper Copper Copper Copper Copper

--Material Galvanized Galvanized Galvanized Galvanized Galvanized Steel Plate

InchesNet Dimension(Width×Depth×Height) îî îî îî îî îî

Inches
