Sida 1/18
All it takes to measure, collect and
analyze energy consumption in
heating and cooling applications
Discover the full range of ultrasonic heating & cooling meters and data readout solutions.
Energy metering | Product overview
sono.danfoss.com
Size | Flow DN15 – DN32 | Qp 0.6 - 6.0 m
3
/h
Temperature | Pressure 5-95°C | PN16
Application Heating
Approvals MID class II B+D (heating)
Power supply
Battery AA-cell 3.6 VDC |
Mains unit: 230 VAC
Modular 1 slot for communication module
Communication
2x wired M-Bus | Wireless M-Bus (OMS) |
2x Pulse in-/output
Data logging Daily, monthly and yearly values
Tools Configurable via SonoApp
IP protection IP65 calculator and IP65 flow sensor
SonoSafe™ 10
Mainstream ultrasonic meter
for heating applications
Meter offerings
The ultrasonic meter SonoSafe™ is a compact and reliable meter
for residential applications. The meter offers a new level of
installation and commissioning simplicity by using SonoApp.
It is also manufactured in accordance with ISO/TS16949 (IATF)
automotive standards ensuring highest manufacturing quality.
Main product benefits
• Open communication protocols/interfaces
enable easy data access and system integration
• Best-in-class battery lifetime (up to 16 years) or 230V mains
powered - lowers replacement frequency
• Configuration via SonoApp (change supply/return, energy
units etc.) and modular construction (exchangeable
communication modules) increases installation flexibility
• Extensive alarms (including tamper and reverse flow detection)
ensure instantaneous fault detection
• Advanced diagnostics (remaining battery lifetime,
transducer signal quality) allow preventive maintenance
and troubleshooting
Target
applications
Technical data
1-2 FAMILY HOUSES
COMMERCIAL
MULTI-FAMILY HOUSES
DISTRICT ENERGY
NETWORKS
2
DISTRICT ENERGY
NETWORKS
Size | Flow DN15 – DN32 | Qp 0.6 - 6.0 m
3
/h
Temperature / Pressure 5-95°C | 5-130°C / PN25
Application Heating, cooling, combined
Approvals
MID class II B+D (heating) | TS (DK) |
PTB (DE) | BEV (AT) | METAS (CH) (cooling)
Power supply
Battery AA-cell 3.6 VDC |
Mains unit: 230 VAC
Modular 1 slot for communication module
Communication
2x wired M-Bus | Wireless M-Bus (OMS) |
2x Pulse in-/output
Data logging Daily, monthly and yearly values
Tools Configurable via SonoApp
IP protection IP65 calculator and IP68 flow sensor
SonoSelect™ 10
High-end ultrasonic energy meter
for heating and cooling
Meter offerings
SonoSelect™ is a compact ultrasonic meter for measuring energy
consumption in heating, cooling and combined heating/cooling
applications designed primarily for use in residential buildings.
High flow measuring frequency (two times per second), robust
housing and transducer design make it an excellent choice for flat
stations with instantaneous hot water preparation.
Main product benefits
• Top of class meter accuracy ensures valid billing of heating,
cooling and instantaneous hot water preparation
• Versions with higher pressure (PN25) and temperature rating
(130°C) are a good match also for primary side installations
and high rise buildings
• High IP rating of flow part (IP68) and calculator part (IP65)
prevent condensation problems in cooling applications
1-2 FAMILY HOUSES
COMMERCIAL
MULTI-FAMILY HOUSES
Target
applications
Technical data
3
