A masterclass performance in

cost efficiency trouble-free operationand

Fact Sheet | VLT® AQUA Drive FC 202

Optimized drive for AC motor-driven

water and wastewater applications.

A user-friendly set-up makes instal-

lation easy. Powerful efficiency

enables owners to reach the highest

level of performance and lowest cost

of ownership.

Featuring a wide range of powerful,

standard features, which can be

expanded with performance-improving

options, the VLT® AQUA Drive is equally

suited to both new and retrofit projects.

Set up the drive quickly and easily with

the user-friendly dialog-based Smart

Start wizard and a quick menu which

provides direct access to the most

important features for water and pump

applications. Collecting the most im-

portant water and pump parameters in

one place significantly reduces the risk

of incorrect configuration.

IP66 enclosure and coated boards

cut down the need for cabinet space,

saving on investment and reducing

installation time.

Instantly benefit from high efficiency,

fast payback and the lowest overall cost

of ownership for water and wastewater

applications.

Product range

1 x 200-240 V AC1.1-22 kW .............................

1 x 380-480 V AC7.5-37 kW .............................

3 x 200-240 V AC0.25-160 kW ........................

3 x 380-480 V AC0.37-1000 kW .....................

3 x 525-600 V AC0.75-90 kW ...........................

3 x 525-690 V AC11-1400 kW* .......................

*Up to 2000 kW available on request

FeatureBenefit

Dedicated features

Dry run detectionProtects the pump

Flow compensation functionSaves energy

2 step ramps (initial/final ramp)

and minimum speed monitor

Protects deep well pumps

Check valve ramp

Protects against water hammering and saves

installation cost for soft close valves

Pipe fill modeEliminates water hammering

Built-in motor alternation featureDuty stand by operation, cost reduction

Sleep Mode and no/low flow detectionSave energy and protect the pump

End of pump-curve detectionPump protection, leakage detection

Pump cascade controllerSaves energy and reduces equipment cost

Built-in Smart Logic ControllerOften makes PLC omissible

Multi-Master Cascade (optional)

Full redundant cascade system for maximum

up-time

DeraggingPreventive/reactive pump cleaning

Back-channel cooling for frame D, E and FProlonged lifetime of electronics

Pre/Post LubricationSystem and pump protection

Free programmable infos/warnings/alerts

Perfect system integration and adaptation

to the application

Flow confirmationSystem and pump protection

Energy savingLess operation cost

VLT® efficiency (98%)Saves energy

Automatic Energy Optimisation (AEO)Saves 3-8% energy

Auto Tuning of Staging SpeedsSmoothens the staging and saves energy

ReliableMaximum uptime

IP20 – IP66 enclosures (depending on power size)Choose the protection class you need

All power sizes available in IP 54/55 enclosuresBroad usability in standard enclosure

Password protectionReliable operation

Mains disconnect switchNo need for external switch

Optional, built-in RFI suppressionNo need for external modules

One Wire safe stopSafe operation/less wiring

Max. ambient temperature up to 50°C

without derating (D-frame 45°C)

Less need for cooling or oversizing

User-friendlySave initial and operation cost

One drive type for the full power rangeLess learning required

Intuitive user interfaceTime saved

Modular designEnables fast installation of options

Auto tuning of PI-controllersTime saved

Payback time indicationMonitor performance

30%

cost reduction in 1

st

year compared with

next best alternative

drives.danfoss.com
