Sida 1/8
DIGITAL SOUND LEVEL METER
USER MANUAL
fonometro
1
read this first
With this meter you have bought a very fine,
versatile and precise measuring tool that
allows you to measure sound pressure levels
in a wide range. Please be aware that this
measuring instrument, however precise, is not
to be used for purposes other than indicating
a sound presure level. No legal proof can be
aquired with this instrument nor can the
manufacturer or distributor of this instrument
be made responsible for any claims originating
from using this tool as a measuring instrument.
This measuring instrument is capable of
indicating very high sound levels, that is, up to
130dB. When being exposed to such sound
levels, even for short periods of time, it is
important to protect your ears. At the same
time protection should be weared at lower
sound pressure levels when exposed to sound
for longer periods. Please study adequate
literature as this is beyond the responsablity of
the manufacturer or distributor of this
measuring instrument.
The sound level meter works on batteries or
an external power adapter. The power
adapter is not included but the batteries are.
There are 6 pcs. of 1,5 Volt AAA model
battery included. When not using the
meassuring instrument for a longer period,
please remove the batteries from the device
to avoid damage to the device caused by
leakage of the batteries.
general
2
As it says in the name, this is a "sound level
meter" that is, it will indicate the sound level
as it is perceived by the human ear. Therefore
the measured sound is filtered using a curve
that mimes the sensivity of the human ear.
The International Electrotechnical Commission
(IEC) has defined several weighting schemes
that are layed down in a standard called ANSI
S1.1-1994 The curve used to match the
human ear is called A-curve. This curve is
used in the sound level meter by default.
When wanting to measure peak sound levels
the device should be switched to use the C-
curve.
LCD display
• Analog bar indicator
• Wide dynamic range
• Auto / manual range
• Fast / Slow response selectable
• Max. value Hold function
• A / C weighting selection
• Date and time display
• AC / DC auxiliary output
• Backlight
• Low power indication
Measurement range: 30 dB - 130 dB
Accuracy: +/-2 dB
Resolution: 0,1 dB
Sample rate: 2 times/s
Frequency range: 20 Hz - 8 kHz
