APOCALYPSE SERIES

1. Introduction

2. Safety instructions

3. Wiring diagrams

4. Filtering, recommended ampliﬁer settings

5. Speciﬁcations

6. Dimensions

7. Box contents

8. Warranty and maintenance info

9. Information on disposal of the electrical and electronic equipment

(for the European countries with separate waste collection)

C O N T E N T S EN

1 . I N T R O D U C T I O N

1. Fasten the speakers properly when installing it in the vehicle. If the component is disconnected during driving, it may cause

serious damage to the passengers of the vehicle or another vehicle.

2. Before installing the components, if possible store the product in it’s original package to avoid accidental damage to the

product.

3. Be careful when installing and dismantling the speaker! Do not let the speaker drop to avoid damage of its moving parts.

4. When working with tools follow safety rules.

5. Before the installation switch oﬀ the head unit and all other audio devices to avoid their damage.

6. Make sure that the location of the speaker does not hinder the proper operation of mechanical and electrical devices of the

vehicle.

7. Do not install components in places exposed to water, excessive humidity, high or low temperature, dust or dirt.

ATTENTION!!! The product may be operated at +5 °C (41F) to +40 °C (104F). In case of moisture condensation, let the product to

dry.

8. When performing plumbing, drilling or cutting works with the car, make sure that there is no wiring, brake lines, fuel pipe or

other structural elements under the place of work. Follow the safety rules! Use protective glasses and gloves.

9. When stretching back the speaker cables make sure that they are not in contact with sharp edges or moving mechanical

devices. Make sure that they are ﬁrmly ﬁxed and protected over the entire length.

10. The diameter of the speaker cables must be selected in accordance with the length and applied power.

11. Never stretch the cables outside of the car and near the moving parts of the car. This can lead to destruction of the

insulating layer, short circuit and ﬁre.

12. To protect the cables use rubber gaskets if the wire passes through a hole in the plate, or other similar materials if it lies

close to the parts exposed to heat.

CAUTION!!! High sound pressure can damage your health!

Please use the common sense when controlling volume!

2 . S A F E T Y I N S T R U C T I O N S

3 . W I R I N G D I A G R A M S

4 Ohm х 2 HFS 8 Ohm

Voice coil Total impedance

S e ria l c o n n e c t io n o f t h e s pe a ke r s

Do not expose your ampliﬁer to loads below the value predetermined by the manufacturer.

Various examples of connection types are given at the pages below. Use these examples to determine the required load

impedance of your connection.

Thank you for purchasing this Deaf Bonce product! Our company loud sound is committed to the creation of extremely

systems with no loss of quality.

To ensure proper use, please carefully read through this manual before using this product. It is especially important that you

read and observe caution’s in this manual. Please keep the manual in a safe and accessible place for future reference.
