Sida 1/24
2
User Guide (English)
Introduction
Box Contents
Axis Loudspeaker User Guide
Power Cable Safety & Warranty Manual
Support
For the latest information about this product (system requirements, compatibility information,
etc.) and product registration, visit denondj.com.
Setup / Connection Diagrams
You can set up your Axis loudspeaker in one of two ways:
Important: Please also see the following Important Safety Instructions chapter.
• Flat: Set the loudspeaker directly on a flat, stable surface (the floor or a low, sturdy table).
You can stack multiple Axis loudspeakers in a column, but make sure that all of them are
of the same model (Axis 8 or Axis 12) and that each loudspeaker’s feet are placed firmly
in the 4 sockets of the unit beneath it.
• Pole-Mounted: Carefully lift the loudspeaker and place the 36 mm hole in its bottom
panel over a standard 35 mm pole or speaker stand.
See the following examples of how to integrate the loudspeaker into your setup.
Note: Items not listed in Introduction > Box Contents are sold separately.
Example 1: 1 loudspeaker with vocal microphone and media player
Connect a dynamic microphone to Input 1 using an XLR or 1/4” (6.35 mm) TRS cable. Make
sure the Line/Mic Selector is set to Mic. Connect a media player (smartphone, tablet, MP3
player, etc.) to Input 2’s RCA connectors using a 1/8”-to-RCA (3.5mm-to-RCA) cable.
Note: Use only dynamic microphones with the loudspeaker unless you are also using an
external phantom power supply.
Dynamic
microphone
Smartphone,
tablet,
MP3 player,
etc.
Power
3
Example 2: 2 loudspeakers with mixer
Connect the left and right output of your mixer to Input 1 of each loudspeaker using XLR or
1/4” (6.35 mm) TRS cables. Make sure the Line/Mic Selectors are set to Line.
Tip: To send the same mix to both loudspeakers, connect both channels of your mixer to the
Inputs 1 and 2 of one loudspeaker, set its Input 1/Mix Selector to Mix, and then connect that
loudspeaker’s Thru Output to Input 1 of the other loudspeaker. Both loudspeakers will then
play identical summed mono mixes.
Tip: To add extension loudspeakers in a “daisy chain” configuration, connect the Thru Output
to the input of your additional loudspeaker. Be sure to set the Input 1/Mix Selector to the
desired setting.
Example 3: 1 subwoofer and 2 loudspeakers with mixer
Using XLR or 1/4” (6.35 mm) TRS cables, connect the left and right output of your mixer to the
inputs of your subwoofer, and then connect each high-pass output of the subwoofer to
Input 1 of each loudspeaker. Make sure the Line/Mic Selectors are set to Line.
Power
Power
Mixer
Power
Mixer
Subwoofer
Power
