Sida 1/10
INSTRUCTION MANUAL
CAR STEREO CD/CDR/CDRW/MP3 PLAYER
WITH PLL FM STEREO RADIO
RDS
DETACHABLE FRONT PANEL
CAD-370
AUX
IN
CAD370(eng).indd 1 1/16/07 4:00:02 PM
E2
LOCATION OF PARTS AND CONTROLS
1. POWER ON/OFF (PWR)
2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER/TA SEEK/
MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/
LOCAL/VOL LAST (SEL)
3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER/TA SEEK/
MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/
LOCAL/VOL LAST (+/-)
4. PRESET STATIONS (1,2,3,4,5,6)
5. function (ALTERNATIVE FREQUENCIES)‘AF’
6. ‘TA’ function (TRAFFIC ANNOUNCEMENT)
7. ’ function (PROGRAM TYPE) ‘PTY
8. DISPLAY (DISP)
9. MODE BUTTON (MODE)
10. BAND (BAND)
11. AUTOMATIC OR MANUAL TUNING (FREQ UP OR FREQ DOWN )
12. AUTO SEEK SEARCH TUNING (A/PS)
13. ‘SCAN’ AUTOMATIC TUNING CONTROL (SCN)
14. MUTE BUTTON (MU)
15. PANEL RELEASE BUTTON ( )
16. LCD DISPLAY
17. CD EJECT BUTTON ( )
18. CD SLOT
19. PAUSE BUTTON
20. INTRO BUTTON (Preview all Tracks)
21. REPEAT BUTTON
22. RANDOM BUTTON
23, 24. + 10 TRACK SEARCH UP/DOWN
25. FRONT AUX IN
AUX
IN
1618 1517 7111 132 3
21 22 23 24 6 25 582019914 1210
4
(1-6)
CAD370(eng).indd 2 1/16/07 4:00:03 PM
E3
53mm
182mm
3
2
182mm
53mm
1
2
1
3
4
INSTALLATION
PRECAUTIONS
• Choose the mounting location carefully so that the unit will not interfere with the normal
driving functions of the driver.
• Avoid installing the unit where it would be subject to high temperatures, such as from direct
sunlight or hot air from the heater, or where it would be subject to dust, dirt or excessive
vibration.
• Use only the supplied mounting hardware for a safe and secure installation.
• Be sure to remove the front panel before installing the unit.
NOTE : Inclination angle for car radio installation must not
exceed 30˚ otherwise the front panel will not open.
Note: Keep the release key in the safe place as you may need it in future to remove the unit
from the car.
Bend these
claws, if necessay
release screw and
bracket
ISO CONNECTOR
RCA Jack Line Out: RCA Jack Line In:
: Red (right) : Red (right)
: White (left) : White (left)
CONNECTOR A
1.
2.
3.
4. MEMORY +12V
5. AUTO ANTENNA OUTPUT
6.
7. +12V (TO IGNITION KEY)
8. GROUND
Note: (connector A no. 7) must be connected by car ignition key in order to avoid that car
battery becomes weak when the car will be not used for long period.
CONNECTOR B
1. REAR RIGHT SPEAKER (+)
2. REAR RIGHT SPEAKER (-)
3. FRONT RIGHT SPEAKER (+)
4. FRONT RIGHT SPEAKER (-)
5. FRONT LEFT SPEAKER (+)
6. FRONT LEFT SPEAKER (-)
7. REAR LEFT SPEAKER (+)
8. REAR LEFT SPEAKER (-)
Maintenance
FUSE REPLACEMENT
If the fuse blows, check the power connection and replace the fuse. If the fuse blows again after the
replacement, there may be an internal malfunction. In this case, consult your nearest repairing center.
Warning
Use the specied amperage fuse for each lead. Use of a higher amperage fuse may cause serious dam-
age.
B
12
34
56
78
12
34
56
78
A
CAD370(eng).indd 3 1/16/07 4:00:05 PM
