Sida 1/4

User Manual

IPO-2030

www.denver-electronics.com

Before connecting, operating or adjusting the product, please read carefully and thoroughly

this user manual. Please keep this user manual in a safe place for future use.

FCC Compliance Statement: This device complies with Part

15 of the FCC rules. Operation is subjected to the following

two conditions: (1)this device may not cause harmful

interference, and (2) this device must accept any

interferencereceived, including interference that may cause

undesired operation.

Products with CE Marking comply with EMC Directive

(2014/30/EU); Low Voltage Directive (2014/35/EU); RED

(2014/53/EU); ROHS Directive (2011/65/EU) issued by the

Commission of the European Community. Compliance

with these directives implies conformity to the following

European Norms:

EMC: EN 301 489

LVD: EN 60950

Radio: EN 300 328

If the camera system no longer functions or can no longer be repaired, it must be disposed of according to the valid statutory regulations.

Disposal of spent batteries/accumulators:

You are required by law (Battery Ordinance) to return all spent batteries and accumulators. Disposing of spent batteries/accumulators with

common household waste is prohibited! Batteries/accumulators that contain hazardous substances are marked with the symbols on the

side. These symbols indicate that it is prohibited to dispose of these batteries/accumulators in the household waste. The abbreviations for the

respective heavy metals are: Cd=cadmium, Hg=mercury, Pb=lead. You can return spent batteries and accumulators that can no longer be

charged to the designated collection points in your community, outlets or wherever batteries or accumulators are sold. Following these

instructions will allow you to fulﬁll the legal requirements and contribute to the protection of our environment!

QUICK START GUIDE

KIT CONTENT :

Camera Antenna

x 1

x 1x 1

Quick Start Guide

Power Adapter

x 1

PRODUCT OVERVIEW

SETUP THE CAMERA

1. APP Download

Download and install the "IPO-2030" APP to your device.

2. Power up The Camera

Connect the power wires to the adapter supplied, and wait until the RED LED indicator becomes

steady on. This process would be ﬁnished within 1 min and make sure the LED is ﬂashing in RED.

3a.Wireless Connection

(1) In the Wi-Fi setting of your smart device. Choose the Wi-Fi router with preﬁx of HD-xxxxxx

(xxxxxx=Camera ID numbers). Then enter the default password 12345678.

(2) Launch the APP, tap to add the camera.

(3) Tap (QR code icon) and scan the QR code label on the back of the camera to bring up the DID

information. Or tap "Search" to locate the camera.

(4) Enter the default password 123456.

(5) Tap “Save” when you done.

(6) Later, APP will request user to modify the default password to private password .

Note: Press and hold the “Reset” button for 5 seconds, the

system will be restored into factory default.

Pan/Tilt Wireless

Camera

x 1

Screw Pack

x 1

Rj45 Connect Jack

Micro SD Card Slot

Microphone

Antenna

Lens

Reset Button

Light Sensor

Mount Bracket.

Ethernet Cable

Power Cable

x 1

Hex Key

FRIENDLY REMINDER

- For video recording, BE SURE TO use CLASS 10 memory card or above (not included). Other kinds of

memory card may cause unexpected results and should be avoided.

- Anytime when you ﬁnd the camera pan/tile function does not perform properly, calibrate the camera

to get correct principle position (refer to step 8 of setup the camera section).

- For better performance, please enable the video hardware acceleration function. This function only for

Andriod (refer to the app introduction section).

För iOS

För Android

APP INTRODUCTION

Follow the steps below for Event Playback

(1) Tap the icon to access the event list section.

(2) Select the time interval for the event list.

(3) Select the ﬁle you want to playback.

(4) If you want to store the ﬁles to the mobile device, tap to download the ﬁles (Best while under

Wi-Fi enviornment due to larger high deﬁnation data size).

(1) (1)-1

(2) (3) (4)

3b.Wired Connection

(1) Make sure your smartphone is connected your Wi-Fi router.

(2) Connect the camera’s Ethernet cable to the Rj45 connect, and power on the camera with adapter.

(3) Launch the APP, tap the “Search” to locate the camera.

(4) Enter the default password 12345678 and save the settings.

(5) Later, APP will request user to modify default password to private password .

Note: In soft AP mode, the RED LED long ﬂashes once followed by 2 short ﬂashes. In normal mode,

the LED is ﬂashing in RED.

4. Wi-Fi Setting

(1) Tap then the advanced setting icon will appear on the screen.

(2) Enter the default password :12345678

(3) Select your Wi-Fi router, and enter its password.

(4) The Camera will oﬄine for around 40 seconds to reboot for Wiﬁ connection. When camera connects

to Wi-Fi router correctly, the RED LED will stay ON.

(5) In the Wi-Fi setting on your smart device again, make sure the Wi-Fi router you are connecting

to is the same as the camera. If not, manually assign to it.

Note: If you fail to add the camera for several times, press and hold the “Reset” button for 5 seconds

to reset it.

Live-View

Camera List

Information

Refresh

Camera Setting

Add Camera

Live View

Snapshot

Video Record

Return

Mute

Setup Camera Position

Arm/Disarm

Rj45 Connect

Power Adapter

Router

Advanced

Enter Admin Password

(default 123456)

Choose the appropriate Wi-Fi

router on your local network

Produktspecifikationer

Varumärke:	Denver
Kategori:	övervakningskamera
Modell:	IPO-2030
Vikt:	792 g
Bredd:	142 mm
Djup:	206 mm
Höjd:	169 mm
Förpackningens bredd:	150 mm
Mobila operativsystem som stöds:	Android
Wi-Fi:	Ja
Maximal upplösning:	1920 x 1080 pixlar
Antal kameror:	1
Inbyggd hårddisk:	Nej
Fast brännvidd:	- mm
Modell:	IP-säkerhetskamera
Rörelsesensor:	Ja
Observationsavstånd (vidvinkel):	- m
Observationsavstånd (tele):	- m
Igenkänningsavstånd (vidvinkel):	- m
Igenkänningsavstånd (tele):	- m
Identifieringsavstånd (vidvinkel):	- m
Identifieringsavstånd (tele):	- m
Produkter per intermodal container (20 fot):	3144 styck
Produkter per intermodal container (40 fot):	7548 styck
Linsdiameter:	- mm
Typ av minneskort:	MicroSD (TransFlash)
Produktens färg:	Svart
Låddjup:	244 mm
Inbyggd kortläsare:	Ja
LED typ:	IR
Formfaktor:	Kupol-formad
mörkerseende avstånd:	10 m
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	-10 - 50 ° C
AC-inspänning:	230 V
Internationellt skydd (IP) kod:	IP66
Video rörelsedetektor:	Ja
Kryptering/säkerhet:	WEP, WPA, WPA2
Placeringar som kan användas:	Utomhus
Anslutningsteknologi:	Kabel & Trådlös
Monteringssätt:	Vägg
Minimibelysning:	- lx
Mörkerseende:	Ja
Totalt megapixel:	2 MP
Bildfrekvens:	30 fps
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	AC
Växelström Frekvens:	50 hz
Högsta minneskortskapacitet:	128 GB
Normalt fokusomfång:	- m
Panoreringsvinkel:	270 - 90 °
Närmsta fokusavstånd:	- m
Detekteringsavstånd (bred):	- m
Detekteringsavstånd (tele):	- m
