Sida 1/4
24" fhd led tv with atv and mpeg-2 dvb-t +
dvb-s + c.i & usb input + pvr function
Instruction Manual
Model NO.: LED-2456DVBTS
Unit
The functions of the TV buttons are described below.
MENU Press to display the OSD menu, Press again to exit the menu. :
CH-/CH+: Press to scan through channels.
VOL-/VOL+: Press to adjust the volume.
They are also can be used to move left/right in the OSD menu screen.
VOL+ button can be used to skip forward to next menu.
INPUT: Press to select the source.
Power: Turn on/off the TV set.
4
Remote Control Window
(keep clear)
LED Indicator
INPUT MENU CH- CH+ VOL- VOL+ POWER
Connecting external devices (continued)
Caution:
Before connecting external devices:
Makes sure to disconnect the appliances from the power supply in order to avoid any
potential damage from occurring.
Make sure to establish the required connection.
Make sure that the connectors are properly and correctly attached before connecting
the appliances to the power supply.
RF: Connect antenna or cable 75 Ohm coaxial to receive TV signal.
R/L in: Connect them to the audio output terminal of DVD.(shared with YPbPr)
VIDEO: Connect it to video output terminal of DVD.
YPbPr: Connect them to the YPbPr video output terminal of DVD.(used in
component source)
POWER:
SWITCH: Power ON/OFF.
Connect to the mains adaptor.
HDMI: Connect it to the HDMI of DVD or other equipment.
USB: For soft Multimedia and Record.
VGA: For PC display.Connect it to the D-Sub 15 pins analog output connector of the PC.
PC-IN: Connect it to the audio output terminal of PC.
SCART: Connect them to the SCART video output terminal of DVD.(used in component source)
Headphone: Connect it to your headphone or other audio equipment.
8
USB(DVB-S):Connect to USB device for multimedia and PVR
LNB IN: LNB OUT:SAT IN LOOP OUT
Common Interface:CI slot.
Switch
USB
out
in
LNB
IN-LNB-OUTUSB
POWER USB HDMI VGA PC-in SCART
Headphone out
Y Pb Pr Video R in L in RF Common Interface
