Operation Instructions

FM/MW/SW1-7

9 BAND RECEIVER

1. Band S witch

2. Tuner

3. Frequency Indicating Window

4. DX.& L OCAL switch

5. Power Indicator

6. FM Ban d button

7. FM Ind icator

8. AM Ban d button

9. AM Ind icator

10. Tunin g Indicator

11. Telescopic Antenn a

12. Suppo rting Buckle

13. Hand Belt

14. Powe r Switch & Vo lume Contro l

15. Earph one Jack

16. External Power Ja ck

17. Batter y Slot (Back)

1. Put two AA1.5V new batteries into the Battery Slot (17) according to th e positive and negative

polarity, or plug exte rnal power in the External Power Jack (16).

2. Press the Power Sw itch & Volume Control (1 4) to turn on the power switch, and adjust it to the

optimum volume.

3. Press the FM Band Switch (6) to receive FM program, meanwhile the FM Indicator (7) lights up .

4. Press the AM Band Switch (8) to receive AM program, meanwhile the AM Indicator (9) lights up .

and move the band selector (1) to receive M W, SW1-7 program,

5. Turn the Tuner (2), watch the Frequency Indicating Window (3) and dial pointer select your

desired program.

6. When the received station is right and station signal is strong, the Tun ing Indicator (10) lights up.

7. When you receive F M or SW station, please pull out the Telescopic Antenna(11)and change its

length and angle for better reception.

8. Receiving MW by using internal magnetic an tenna, and you can get b etter reception by rotatin g

the direction of the r adio.

11. When you do not w ant to listen to the radio, please move the Power Switch & Volume Control

(14) down.

9. Local & DX sensitiv ity switch is set in the rad io, convenient for you to receive SW, FM program s

under different circu m stances. In general, p lease set the switch to the position of DX; if you

receive local station s with strong signal or meet strong electric jam, please set the switch to the

position of Local.

10. In order not to affect others, please insert the earphones in the Earphones Socket (15) (the

speaker inside the radio disconnects autom atically), you can listen to the radio by earphones .

11 12

1. Frequency Range:

MW 525-1605 KHz

FM 87-108.5 MHz

SW1 5.95-6.20 MHz

SW2 7.10-7.30 MHz

SW3 9.50-9.90 MHz

SW4 11.65-12.05MHz

SW5 13.60-13.80MHz

SW6 15.10-15.60MHz

SW7 17.50-17.90MHz

2. Sensitivity:

MW 3mV/m

FM 22dB

SW 40dB

3. Speaker: 57mm/4 /0.25W

4. Power: DC 3V, two AA1.5V batteries

5. Output power: 100mW

6. Size: 110x70x26mm

7. Weight: 150g

≤

Φ Ω

≥

English

DENVER TWR-804

Produktspecifikationer

Varumärke:	Denver
Kategori:	Radio
Modell:	TWR-804
Inbyggd display:	Nej
Vikt:	120 g
Bredd:	109 mm
Djup:	24 mm
Höjd:	70 mm
LED-indikatorer:	Ja
Frekvensband:	AM, FM, MW
Inbyggda högtalare:	Ja
Typ av tuner:	Analog och digital
FM-antenn:	Ja
Antal batterier:	2
Produktens färg:	Svart
Hörlursutgång:	Ja
MP3-uppspelning:	Nej
väska:	Ja
Apple-kompatibel dockningsmöjlighet:	Stöds inte
På / av-knapp:	Ja
Strömkälla:	DC/Batteri
Typ av radio:	Bärbar
FM band:	87 - 108.5 MHz
AM band:	525 - 1605 kHz
SW-bandområdet:	17.5 - 17.9 kHz
