Sida 1/3
MICROBOX AMPLIFIED
LOADED ENCLOSURE
MICROBOX AMPLIFIED
LOADED ENCLOSURE
© 2024 Diamond Audio. All rights reserved.
( A division of CV & DA Holdings, Inc.)
DESMB8A/DESMB8DA
DESMB10A/DESMB10DA
DESMB12A
DESMB8A/DESMB8DA
DESMB10A/DESMB10DA
DESMB12A
DES
SERIES
DES Microbox Manual 2023 | Spread 1 of 2 - Pages (6,1)
Diamond Audio (a division of CV & DA Holdings, Inc.) warrants this product to be free from defects in
material for a period of one (1) year from the original date of purchase provided it was purchased from
an authorized DAT retailer within the United States. However, if this product was installed by authorized
DA retailer, the warranty period will be extended to two (2) years.
THIS WARRANTY IS NOT TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASE OF THIS
PRODUCT IN ITS ORIGINAL INSTALLATION. Original purchaser must reside in the United States and be
able to provide proof of purchase and installation with the sales from the authorized DAT retailer and
completion of online registration that sold and installed the product.
Should a manufacturing defect occur during above said warranty period, DA will replace or repair the
defective product with a product of the same or equivalent value and performance.
Damage or failure caused by any of the following is not covered under this warranty policy: negligence,
improper use, abuse, product modification, unauthorized repair attempts, accident, acts of God,
misrepresentations by DA retailers, and improper/inadequate packaging during return shipping.
Warranty is void if serial numbers have been removed, altered or defaced.
In the event a DA product should require service, you should visit the authorized DA retailer you
purchased the product from and they can expedite your claim. All claims must fall into the guidelines
listed above and be accompanied by a copy of the original sales and installation receipt from that
authorized DA retailer.
Product returned for warranty service must be freight-prepaid, properly packaged and clearly marked
with the Return Authorization (RA) number issued by DA. Any product returned to DAT that is improperly
packaged, does not have a RA number clearly marked on the package, or never received a RA number
may be refused upon delivery. DA does not assume responsibility for lost or misdirected product.
Repair or replacement under this warranty is the exclusive remedy of the consumer. DA shall not be
liable for any incidental or consequential damages for breach of any expressed or implied warranty on
this product. Some states do not allow the exclusion or limitation of incidental or consequential damages,
or allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not
apply to you. This warranty gives you specific legal rights and you may also have other rights that may
vary from state to state.
Customer outside the United States should contact their local sales office to obtain information on
pricing, exchange unit availability, instructions, service and warranty/non-warranty replacement
or repair.
3761 South Hill St.
Los Angeles, CA 90717
Tel: 213-261-4161
Fax: 213-947-4767
Web: diamondaudio.com
Facebook.com/DiamondAudio
213-261-4161
helpdesk@dat-cvm.com
© 2024 Diamond Audio. All rights reserved.
( A division of CV & DA Holdings, Inc.)
© 2024 Diamond Audio. All rights reserved.
( A division of CV & DA Holdings, Inc.)
A
B
C
B
C
A
SINGLE
DUAL
DES Microbox Manual 2024 | Spread 2 of 2 - Pages (2,3)
Dimension
Length (A)
Height (C)
Depth (B)
in. (mm)
in. (mm)
in. (mm)
Unit
DESMB8A DESMB10A
18” (457.2)
6.4” (156.2)
12” (305)
20.9” (533)
7.8” (200)
12.9” (330)
DESMB12A
24” (609)
11” (277)
14.4” (368)
Dimension
Length (A)
Height (C)
Depth (B)
in. (mm)
in. (mm)
in. (mm)
Unit
DESMB8DA DESMB10DA
34.4” (875.5)
6.4” (156.2)
12” (305)
40.3” (1024)
7.8” (200)
12.9” (330)
Model
DESMB8A
DESMB10A
DESMB8DA
2Ω
Nominal Impedance
RMS Power MAX Power
250W
500W
Grille
OD187.2, H29
DESMB10DA
DESMB12A
2Ω
2Ω
2Ω
2Ω
250W
500W
OD187.2, H29
350W
700W
OD238.6, H29.5
500W
1000W
OD238.6, H29.5
500W
1000W
OD287.2, H29.5
About the Diamond Audio Experience:
Congratulations, you have just purchased the finest mobile audio products on the market to date.
At Diamond Audio, our products represent the latest advances in acoustic technology in sound
reproduction for your vehicle. Diamond Audio products are designed, developed, and engineered using the
latest innovative materials and components to provide the finest sound reproduction possible. Every
Diamond Audio product has been verified and tested by Klippel equipment to ensure the best sound and
most reliable product on the market today. If installed correctly, Diamond Audio products will provide
many years of the ultimate listening experience.
Please note that prolonged exposure to sound pressure levels in excess of 100dB can cause permanent
hearing loss. Using Diamond audio products can exceed that level, so please exercise restraint in its
operation to preserve your ability to enjoy its high-fidelity sound for
years to come.
Diamond Audio recommends an authorized Diamond Audio dealer professionally install our products to
achieve the best possible system performance and longevity. Installation by a professional will ensure an
authentic Diamond Audio listening experience and the sound you would expect from Diamond Audio
products. Also, doing this will extend your warranty from one year to two years.
Diamond Audio’s Microbox Enclosure system delivers impressive bass output in a small package! These
Microbox Enclosures come preloaded with a single or dual pair option of true DES Series subwoofers and
powerful internal amplifiers for the perfect match up. After many hours of fine-tuning this subwoofer and
developing the perfect slot-port application, these Microbox subs outperform even larger systems.
Constructed with high-strength MDF, extensive bracing, and lock-tight fastening, it means no leaks and
distortion-free bass response. - Go ahead, Hear the Music!
These MICROBox subwoofer systems pack a punch. We highly recommend bolting the enclosures down
with L brackets or some restraint to keep them from moving around when the vehicle is in motion. The
amplifiers are equipped with quick disconnects if the enclosure needs to be removed or replaced for
space considerations.
We recommend a minimum of 8GA copper power wire for all models for the best amplifier
performance.
NO CCA wire. CCA wire will void your warranty, reduce the performance of your system, and could
cause harm to your system or vehicle.
