Sida 1/20
Uni ersal HD over Coaxv®
5MP Vandal Dome Camera
DWC-V8553TIR/ DWC-V8563TIR
User’s Manual Ver. 11/18
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
DWC-V8553TIR, DWC-V 8563TIR
Table of Contents
1 FEATURES............................................................ 3
2 DIMENSIONS ........................................................ 4
2.1 -DWC V8553TIR ............................................. 4
2.2 -DWC V8553TIR ............................................. 5
3 PRODUCT ACCESSORIES..................................... 6
4 INSTALLATION...................................................... 7
5 CHANGING THE CAMERA’S SIGNAL ..................... 8
6 CONNECTING TO DVR/ENCODER......................... 9
7 ADJUSTING THE CAMERA ANGLES .................... 10
8 OSD MENU TREE ................................................ 11
8.1 LENS .......................................................... 11
8.2 EXPOSURE ................................................. 11
8.3 WHITE BALANCE ........................................ 12
8.4 DAY&NIGHT ................................................ 12
8.5 ADJUST ...................................................... 13
8.6 -AUTO FOCUS ............................................. 14
9 TROUBLESHOOTING .......................................... 15
10 SPECIFICATIONS ................................................ 16
10.1 -DWC V8553TIR ........................................... 16
10.2 -DWC V8563TIR ........................................... 17
11 LIMITS & EXCLUSIONS........................................ 18
12 WARRANTY INFORMATION................................. 19
Universal HD over Coax® 5MP Camera
3
1 FEATURES
§ Universal HD over Coax® - - -Technology supports HD Analog, HD TVI, HD CVI
and all analog to 960H signals
§ 5MP 1/2.7" image sensor at 20fps / 4MP at real- time 30fps
§ 2.8mm fixed lens (DWC-V8553TIR model)
§ 2.8~12mm varifocal lens with motorized zoom and focus (DWC-V8563TIR
model)
§ Digital Wide Dynamic Range (D- WDR)
§ OSD control via Coaxial (UTC)
§ 100' range IR
§ 3D digital noise reduction
§ True day/night with mechanical IR cut filter
§ Auto gain control (AGC)
§ Backlight compensation (BLC)
§ Auto white balance (AWB)
§ IP66 certified weather and tamper resistant
§ IK- 10 impact resistant
§ 5 year warranty
