IMPORTANT:

This booklet should be left with the user after

installation and demonstration

Installation and User Guide

V 8.5/9.5KWERVE

1 – Pack Contents 3

2 – Installation Check List 3

3 – Important Safety Information 4

4 – General Installation Layout Guide 5

5 – Important Installation Information 6

6 – Fixing the Shower to the Wall 6

7 – Product Positioning Guide 7

8 – Plumbing Connections 8

9 – Electrical Connections 9-10

10 – Fitting the Front Cover 10

11 – Riser Rail Fitting Instructions 11

12 – Commissioning the Shower 12

13 – Troubleshooting Checklist for the Installer 13

1 – Important Safety Information 14

2 – Operating the Shower 15

3 – How Your Shower Works 16

4 – Routine Maintenance 16

5 – Troubleshooting and FAQs 17

6 – Troubleshooting Checklist for the Installer 18

7 – Energy Related Product Directive (ErP) 19

User Guide

Installation Guide

IMPORTANT: This appliance can be used by children aged from 3

years and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

The shower spray head MUST be cleaned regularly to remove

scale and debris. The frequency of the cleaning will vary according

to the local water quality. If the water outlet temperature becomes

hot and you are unable to obtain cooler water, immediately check

the shower handset for blockage. See User Guide Section 4 for

cleaning instructions.

Do not operate shower if frozen, or suspected of being frozen. It

must thaw out before using.

Contents

Installation Guide

Shower Unit

Shower Handset

Riser Rail Tube

Riser Rail Brackets x 2

Riser Rail Height Adjuster

Flexible Shower Hose

Soap Dish

Screw Pack

Installation and User Instructions

Please make sure ALL components are included before starting the installation.

Installation Guide

1. Pack Contents

2. Installation Check List

Check that the water supply will satisfy requirements

Check that water & cable entry points of the unit meet requirements

Check that the electric supply will satisfy requirements

Select a suitable position for the shower

Follow plumbing installation section

Follow electrical installation section

Fit to the wall & connect the shower supplies

Commission the shower in the way described

Fit the front cover & aligning the controls

Familiarise yourself with the user operating instructions
