Sida 1/12

– 1 –

16L & 20L DEHUMIDIFIERS

INSTRUCTION MANUAL

GDDEK series (GDDEK16 and GDDEK20)

– 2 –

Please take time to read this manual carefully before use and

save it for future reference.

CONTENTS

Speciﬁcations 2

Before use 3

Control Panel 4

Operation 5

Where to position 6

Parts 7

How it works 8

Drainage 9

Maintenance 10

Trouble shooting 11

SPECIFICATIONS

Model no. GDDEK16 GDDEK20

Power supply 220-240V~, 50Hz

Dehumidiﬁcation capacity 30oC, 80% 16 L/day 20L/day

Power / Ampere consumption* 30oC, 80% 240W / 1.1A 370W / 1.7A

32oC, 80% 260W / 1.2A 390W / 1.8A

Air volume (max.) 150M3/h 150M3/h

Compressor Rotary

Refrigerant R134a

Working range 5 ~ 32oC

Water tank 5L

Size (WxDxH) With castors - 336 x 210 x 569 mm

Without castors - 336 x 210 x 547 mm

N.W. 10.4 kg 11 kg

• *please refer to the rating label placed on the product.

• Test condition for data in our rating label is as per safety regulation: EN 60335-2-40

– 3 –

BEFORE USE

CAUTION!

Always keep the unit in vertical position.

Leave the unit to stand for one hour before connecting to the mains supply after

transport or when it has been tilted (e.g. during cleaning).

Keep all foreign objects away from the air intake or output openings.

The mains supply must conform to the speciﬁcation shown on the rating plate at the

back of the unit.

If the supply cord is damaged, it must be replaced by an approved service

representative or a similar qualiﬁed person.

Never use the plug to start and stop the unit. Always use the button on the control

panel.

Before moving the unit, ﬁrst switch off, then unplug and empty the water tank.

Don’t use bug sprays or other ﬂammable cleaners on the unit.

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the

appliance by a person responsible for their safety. Children should be supervised to

ensure that they do not play with the appliance.

IMPORTANT!

Do not use this unit at ambient temperatures below 5

oC, to prevent the possibility of a

heavily iced up evaporating coil.
