OPTIMYST INSET

RTOPI20BR & RTOPI20CH

This product complies with all the required Product Safety, Electromagnetic Compatibility and Environmental Standards. This product

is fully compliant with the LVD, EMC, RoHS and Eco Design Directives.

08/51576/0 Issue 8

OCN 11838

EN : This product is only suitable for well insulated rooms or occasional use. DE : Dieses Produkt ist nur für gut isolierte Bereiche oder gelegentli-

che Verwendung geeignet. FR : Ce produit convient uniquement à des endroits bien isolés ou pour un usage occasionnel. IT : Questo prodotto è

adatto solo per spazi ben isolati o per uso occasionale. ES : Este producto sólo es adecuado para espacios bien aislados o un uso ocasional. NL :

Dit product is uitsluitend geschikt voor goed geïsoleerde ruimten of voor sporadisch gebruik. PL : Produkt ten jest odpowiedni wyłącznie do dobrze

odizolowanych miejsc lub do okazjonalnego użytku. NO : Dette produktet egner seg kun for godt isolerte rom eller sporadisk bruk. RO : Acest

produs este adecvat exclusiv spaţiilor bine ventilate sau utilizării ocazionale. CZ : Tento výrobek je vhodný pouze do dobře izolovaných prostor

nebo k příležitostnému použití. DK : Dette produkt er kun egnet til velisolerede rum eller lejlighedsvis brug. PT : Este produto somente é adequado

para espaços bem isolados ou uso ocasional. SE : Denna produkt är endast avsedd för välisolerade utrymmen eller tillfällig användning. FI : Tämä

tuote soveltuu ainoastaan hyvin eristettyihin tiloihin tai satunnaiseen käyttöön. SK : Tento výrobok je vhodný len pre dobre izolované priestory alebo

na občasné použitie. SI : Ta izdelek je primeren le za dobro izolirane prostore ali za občasno uporabo. HR : Ovaj proizvod je pogodan samo za

dobro izolirane prostore ili povremenu upotrebu. HU : Ez a termék csak jól szigetelt terekhez vagy eseti használatra alkalmas.

Dimplex OPTIMYST Inset Fires

Model: RTOPI20BR, RTOPI20CH

IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR

FUTURE REFERENCE

Important Safety Advice:

When using electrical appliances, basic precautions should always be followed to

reduce the risk of re, electrical shock and injury to persons, including the following:

If the appliance is damaged, check with the supplier before installation and operation.

Do not use outdoors.

Do not use in the immediate surroundings of a bath, shower or swimming pool.

Do not locate the heater immediately below a xed socket outlet or connection box.

This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved. Children shall not play

with the appliance. Cleaning and user mantenance shall not be made by children with

out supervision.

Children of less than 3 years should be kept away unless continuously supervised.

Children aged from 3 years and less thab 8 years shall only switch on/o󰀨 the

appliance provided that it has been placed or installed in its intended normal

operating position and they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the hazards involved. Children

aged from 3 years and less than 8 years shall not plug in, regulate and clean the

appliance or perform user mantenance.

CAUTION

Some parts of this product can become very hot and cause burns. Particular attention

has to be given where children and vulnerable people are present.

Do not use this heater in series with a thermal control, a program controller, a timer or

any other device that switches on the heat automatically, since a re risk exists when

the heater is accidentally covered or displaced.

Ensure that furniture, curtains or other combustible material are positioned no closer

than 1 metre from the heater.

In the event of a fault unplug the heater.

Unplug the heater when not required for long periods.

Although this heater complies with safety standards, we do not recommend its use on

deep pile carpets or on long hair type of rugs.

The appliance must be positioned so that the plug is accessible.

If the supply cord is damaged it must be replaced by the manufacturer or service

agent or a similarly qualied person in order to avoid a hazard.

Keep the supply cord away from the front of the heater.

WARNING: In order to avoid overheating, do not cover the heater. Do not place

material or garments on the heater, or obstruct the air circulation around the heater.

The heater carries a DO NOT COVER warning.

Technical Information :

with mechanic thermostat room temperature control.

General.

Unpack the heater carefully and retain the packaging for possible future use, in the event of moving or returning the re to

your supplier.

The re incorporates a ame eect, which can be used with or without heating, so that the comforting eect may be enjoyed

at any time of the year. Using the ame eect on its own only requires little electricity.

The heater is designed for use inset into a 407mm (16”) or 457mm (18”) wide by 559mm (22”) high replace opening or

freestanding - see also section ‘Installation Instructions’.

A 2kw fan heater is discreetly positioned in the canopy of the re provides heating in cold weather. Switching allows half

or full heat. A distance of 1 metre (39”) must be maintained between the front of the heater and any surrounding furniture,

overhanging curtains or other obstrustions.

To reduce heat loss and to prevent any chimney up draft aecting the operation of your inset re we recommend they the

chimney ue is sealed o.

Before connecting the heater check that the supply voltage is the same as that stated on the heater.

Please note: Used in an environment where background noise is very low, it may be possible to hear a sound which is related

to the operation of the ame eect. This is normal and should not be a cause for concern.

Electrical connection.

WARNING – THIS APPLIANCE MUST BE EARTHED.

This heater must be used on an AC ~ supply only and the voltage marked on the heater must correspond to the supply voltage.

Before switching on, please read the safety warnings and operating instructions.

PLEASE RETAIN THIS USER’S GUIDE FOR FUTURE REFERENCE

Only use ltered tap water in this appliance.

Always ensure that the appliance is sitting on a level surface.

If you intend not using the appliance for longer than a week, drain the water from sump and water tank and dry the

sump.

Once installed, never move this appliance or lay on its back, without draining the water from sump and water tank.

The water tank, sump, sump lid, tank cap and air lters must be cleaned once every week, particularly in hard water

areas.

The appliance should never be operated if the lamps are not working.

The lamps should be regularly inspected as described under ‘Maintenance’ and ‘Changing lamps’.

Installation Instructions

Before installing this appliance in an existing chimnney, we recommend that;

1. You have your chimney cleaned by a competent chimney sweep.

2. You block o the chimney ue.

This procedure is important for the ecient operation of the heating unit and will also reduce heat loss up the chimney.

Installation.

Ensure that all packing items are removed (read any warning labels carefully).

Retain all packing for possible future use e.g. in the event of moving or returning the appliance to your supplier.

To install the appliance;

1. Clean the area where the re will be installed e.g remove ash residue from an existing replace.

2. Use the two adjustable supports at the rear of the appliance to ensure that the re is level.

3. Make sure the unit is switched OFF.

4. Hold the re by the sides of surround and gently manoeuvre into position. Plug the re into a 13amp/240 volt outlet. Ensure

that the supply cable is not trapped under the re such that it might cause it to be damaged.

Before using the manual controls rstly ll the water tank (See ‘Maintenance’, ‘Filling the water tank’).

Model No: RTOPI20BR, RTOPI20CH

Heat Output 230V 240V

Nominal Heat Output P

Nom

1.8 - 2.0 kW

Minimum Heat Output P

min

1.0 - 1.1 kW

Maximum Continous Heat Output P

max,c

1.8 - 2.0 kW

Auxiliary Electricity Consumption 0.0 0.0 kW

In Standby mode el

0.45 - 0.48 W
