Contact Details



Pleasenotethat some contact ofthe details on 

thisPDFdocumentmaynotbe current.



Pleaseuse  the following detailsifyouneedto

contactus:



Telephone:0844 879 3588

Email:customer.services@gdcgroup.co.uk



The widecustomer alsosupportsection websiteofour  features a

rangeof ofinformationwhichmaybe use availabletoyouandis 

24 ahours day.Itincludes:



• Operating   and installation instructions

• Easy       ‘How to use’ guides for storage heaters

• Service  and repairs

• Wheretobuyourproducts

• Literature downloads

• Heating  requirement calculator



 ‐Visit www.dimplex.co.uk/support

A division of GDC Group Ltd

Millbrook House Grange Drive Hedge End Southampton SO30 2DF

www.dimplex.co.uk

istered No: 1313016 En

land

VAT GB 287 1315 50004

EEE Producer Registration Number –

WEE/GE0057TS

Paper from sustainable sources

640

620 390

Dimensions

(millimetres)

Installation and Operating Instructions

08/50672/1 Issue 1

Dimplex Stockbridge Stove

Model: SKG20BL

Important Safety Advice:

When using electrical appliances, Basic precautions

should always be followed to reduce the risk of fire,

electrical shock, and injury to persons, including the

following:

If the appliance is damaged, check with the supplier

before installation and operation.

Do not use outdoors.

Do not use in the immediate surroundings of a bath,

shower or swimming pool.

Do not locate the heater immediately below a fixed

socket outlet or connection box.

Do not cover the heater. Do not place material or

garments on the heater, or obstruct the air circulation

around the heater, for instance by curtains or furniture,

as this could cause overheating and a fire risk.

This appliance is not intended for use by children or

other persons without assistance or supervision if

their physical, sensory or mental capabilities prevent

them from using it safely. Children should be

supervised to ensure that they do not play with the

appliance.

Do not use this heater in series with a thermal control,

a program controller, a timer or any other device that

switches on the heat automatically, since a fire risk

exists when the heater is accidentally covered or

displaced.

Ensure that furniture, curtains or other combustible

material are positioned no closer than 1 metre from

the heater.

In the event of a fault unplug the heater.

Unplug the heater when not required for long periods.

Although this heater complies with safety standards,

we do not recommend its use on deep pile carpets or

on long hair type of rugs.

The appliance must be positioned so that the plug is

accessible.

If the supply cord is damaged it must be replaced by

the manufacturer or service agent or a similarly

qualified person in order to avoid a hazard.

Keep the supply cord away from the front of the heater.

Introduction

These fires incorporate a flame effect, which can be used

with or without heating, so that the comforting effect may be

enjoyed at any time of the year. The flame effect is provided

by a low wattage motor and two 60 watt lamps. Using the

flame effect on its own, therefore, requires little electricity.

The manual controls are located behind the firebox doors.

The remote control is packed separately in the carton. A choice

of 1kw or 2kw heat output is provided by the fan heater, which

is concealed beneath the unit.

These models are designed to be free standing and are

normally positioned against a wall.

Please note: Used in an environment where background

noise is very low, it may be possible to hear a sound which

is related to the operation of the flame effect. This is normal

and should not be a cause for concern.

Electrical connection

WARNING – THIS APPLIANCE MUST BE EARTHED

This heater must be used on an AC ~ supply only and the

voltage marked on the heater must correspond to the supply

voltage.

Before switching on, please read the safety warnings and

operating instructions.

In the event of replacing the fuse in the plug supplied, a 13

amp fuse approved by ASTA to BS1362 must be used.

Fig. 1

IMPORTANT: THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE

Operation

The controls are located behind the doors (see Fig. 2).

Connect the fire to your electricity supply.

Fig. 2

Note: When either the remote control or the manual controls

are used, the neon’s will come on for 3 seconds indicating

the relevant setting (see fig. 3).

neon’s for indicating

the operation level

Fig. 3

1. Slide open the battery cover on the back of the remote

control

2. Install two AAA batteries into the remote control (see

Fig. 4)

3. Replace the battery cover.

Battery information

Fig. 4

Batteries

Discard leaky batteries

Dispose of batteries in the proper manner according to

Provincial and local regulations. Any battery may leak electrolyte

if mixed with a different battery type, if inserted incorrectly, if all

the batteries are not replaced at the same time, if disposed of

in a fire or if an attempt is made to charge a battery not intended

to be recharged.

Fig. 5

Manual or Remote Operation

Thermal Safety Cut-out

A thermal safety cut-out is incorporated in the heater to

prevent damage due to overheating.

This can happen if the heat outlet was restricted in any way.

The heater will switch on once the obstruction has been

removed and the heater has cooled. If the cut-out continues

to operate intermittently, the heater should be switched off

and a service agent contacted.

Maintenance

WARNING: ALWAYS DISCONNECT FROM THE POWER

SUPPLY BEFORE ATTEMPTING ANY MAINTENANCE.

Remote Control

Warning: it takes time for

the receiver to respond

to the transmitter. Do not

press the buttons more

than once within two

seconds for correct

operation.

To turn off any of the

settings

Press the button once

Setting Operation Indication

Flame effect Press the ‘I’ button once Bottom Neon

Flame effect & 1kW heat Press the ‘I’ button again Bottom &

Middle Neon

Flame effect & 2kW heat Press the ‘I’ button again All 3 Neon’s

= Standby

= On

Note : The ON/OFF Switch must first be turned on to

operate either the manual or the remote controls.

Thermostat (T) - see Fig. 2

In order to maintain a certain room temperature, set

thecontroller to ‘max.’. Operate the appliance at full power

untilthe required room temperature is reached. Set back

thethermostatic controller until the appliance switches off

withan audible “click”. This temperature will be kept

almostconstant by the thermostatic control switching on

and offautomatically.Please note that the appliance can

only beswitched on when the thermostat setting is higher

then theroom temperature.
