SpeediChannel™
System Installation
S
p
e
e
d
i
C
h
a
n
n
e
l
i
s
p
r
o
d
u
c
e
d
w
i
t
h
1
0
0
%
r
e
n
e
w
a
b
l
e
e
n
e
r
g
y
Contents
Introduction
3 DiversiTech Speedichannel™ System
4 Features and Benets
System Installation
6 Step 1
7 Step 2
8 Step 3
9 Step 4
10 Step 5
11 Step 6
Installation Diagrams
12 Indoor and Outdoor installations
14 Flex Joint and Drain Hose diagrams
16 Line Set conguration
17 Air Handler installations
Sizing Chart
21 Dimensions and Capacities
Technical Information
22 General data and safety information
Mini Component Guide
23 Product information and product layout
2
I
N
T
R
O
D
U
C
T
I
O
N
3
DiversiTech SpeediChannel™ System
DiversiTech SpeediChannel™ is an innovative channel system used to
cover air conditioning line sets. The two part system has a base and a
cover. The base is fastened to a wall or ceiling, then a clever little plastic
clip ( ) snaps into a channel already molded into the base. SpeediClip™
SpeediClip™ is the fastest, most convenient way to complete a line set
cover installation. Then, using standard cable ties, the line set, cables, con-
trol wires, and/or condensate drain line are fastened in place. The cover
then simply snaps on top of the base.
The SpeediChannel™ system is available in three widths – 3”, 4”, and 6”.
Each piece of SpeediChannel™ is 6-1/2 feet long. A complete line of cou-
plings, elbows, and tees are available for the SpeediChannel™ system.
Manufactured from rigid PVC, the SpeediChannel™ system is a natural
color that is a very close match to the typical mini split condensing unit
case. However, the SpeediChannel™ system can be painted as desired
to match any wall color. The PVC used in the SpeediChannel™ system is
resistant to UV light, and is UL rated.
DiversiTech recommends attaching the
base to the wall or ceiling and the line
sets to the system every 15” to allow for
the system to carry the full weight of the
line sets.
The SpeediChannel™ system can also
be used inside.
