User Manual

ZENMUSE H20 SERIES

Using this Manual

Legend

Warning Important Tips

DJI Pilot App Download

The DJI Pilot app is required when using Zenmuse H20 series.

Scan the QR code to download and install the app.

Searching for Keywords

Search for keywords such as “battery” and “install” to nd a topic. If you are using Adobe Acrobat

Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to that section.

Printing this Document

This document supports high resolution printing.

Caution

1. When not in use, store the Zenmuse H20 series in the storage case and replace the desiccant

packet as necessary to prevent fogging the lenses due to excessive ambient humidity. If the

lenses fog up, the water vapor will usually dissipate after turning on the device for a while. The

recommended storage environment is a relative humidity less than 40% at a temperature of 20±5 ℃.

2. Do not expose the infrared camera lenses to a strong energy source such as the sun, lava or laser

beam. The temperature of the observation target should not exceed 800℃, otherwise it will burn

the camera and cause permanent damage.

3. Do not place the product under direct sunlight, in areas with poor ventilation, or near a heat source

such as a heater.

4. Do not frequently power on/off the product. After it is turned off, wait at least 30 seconds before

turning back on, otherwise the product life will be affected.

5. Under stable laboratory conditions, the Zenmuse H20 series achieves an IP44 protection rating by

IEC60529 standards. However, this protection rating is not permanent and may reduce over time

after long-term use.

6. Make sure the gimbal port and gimbal surface are free from any liquid before installation.

7. Make sure the gimbal is securely installed onto the aircraft, the microSD card slot cover is clean

and rmly in place.

8. Make sure the gimbal surface is dry before opening the microSD card slot cover.

9. Do not plug or unplug the microSD card during use.

10. Do not touch the surface of the camera lenses and keep it away from hard objects, as doing so

may lead to blurred images and affect the imaging quality.

11. Clean the surface of the camera lenses with a soft, dry, clean cloth. Do not use alkaline

detergents.
