ZENMUSE H4-3D

2015.1

V1.0

User Manual

Warning & Disclaimer

The Zenmuse H4-3D gimbal is calibrated before delivery. No adjustment or modication to the

gimbal is required or recommended.

Ensure the camera is mounted to the gimbal before powering on your aircraft.

The H4-3D gimbal is nely calibrated according to the specied camera model and lens (GoPro

Hero4 Black) before delivery. You do not need to perform extra calibration. Do not attempt to

modify the gimbal or mount extra components/devices (such as a lter, lens hood, etc.) to the

camera. Be sure to use a DJI approved battery, otherwise the performance of the gimbal may be

affected.

The H4-3D gimbal is compatible with following DJI ight control systems: NAZA-M, NAZA-M V2,

WooKong-M, Phantom 2 and A2. To optimize the gimbal’s performance, download the relevant

Assistant for your ight controller and upgrade the rmware.

Make sure to operate your aerial system in the safest manner possible. We strongly recommend

that you remove all propellers, use a power supply from the R/C system or ight pack battery,

and keep children away when calibrating and conguring the gimbal. Observe the procedures

contained in this manual to mount and connect gimbal to your aircraft. Users of this product

should respect the AMA’s National Model Aircraft Safety Code.

DJI has no control over use, setup, nal assembly, modication (including use of non-specied

DJI parts i.e. motors, ESCs, propellers, etc.) or misuse, and no liability shall be assumed

nor accepted for any resulting damage or injury. By the act of use, setup or assembly, the

user accepts all resulting liability. DJI assumes no liability for damage(s), injuries or legal

responsibilities incurred directly or indirectly from the use of this product.

DJI and Zenmuse are registered trademarks of DJI. Names of product, brand, etc., appearing in

this manual are trademarks or registered trademarks of their respective owner companies. This

manual shall be reproduced in any form without the prior written consent or authorization of DJI.

Legend

Important Hints and Tips

Contents

Warning & Disclaimer

Legend

Prole

In The Box

Installation

Gimbal Description

Installing H4-3D onto an Aircraft

Camera Installation

Final Checks

GCU Connection

Connecting the GCU and Flight Control System

GCU and Flight Control System Connection

Video Connection

Conguration

Driver and PC Assistant Installation

PC Assistant Interface

Channel Setting

Firmware & Software Upgrade

Test Flight

Pre-ight Checklist

Gimbal Test

Appendix

Troubleshooting

Settings When Using the A2 Flight Control System

Specications

Produktspecifikationer

Varumärke:	DJI
Kategori:	Inte kategoriserad
Modell:	Zenmuse H4-3D
Vikt:	168 g
Bredd:	103 mm
Djup:	92 mm
Höjd:	80 mm
Certifiering:	FCC, CE
Kompatibilitet:	GoPro Hero4
Produktens färg:	Svart
Rotation:	Ja
Hållbarhetscertifiering:	RoHS
Svängarm:	Ja
