Sida 1/8
Form No. 3317050.000 12/17 | ©2017 Dometic Corporation
REFRIGERATION
COOLERS
EN
CF Series and CFX Series
Technical Specifications and Trouble Shooting
USA & Canada
Service Office
Dometic Corporation
1120 North Main Street
Elkhart, IN 46514
Service Center &
Dealer Locations
Visit:
www.dometic.com
Read these instructions carefully.
1 EXPLANATION OF SYMBOLS AND SAFETY INSTRUCTIONS
This manual has safety information and instructions to help you eliminate or reduce the risk of accidents
and injuries.
1.1 Recognize safety information
This is the safety alert symbol. It is used to alert you to potential physical injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death. Refer to this product’s installation/
operation manual for additional relevant safety information.
1.2 Understand signal words
A signal word will identify safety messages and property damage messages, and will indicate the degree or level
of hazard seriousness.
indicates a hazardous situation that, if not avoided, could result in death or serious injury.
indicates a hazardous situation that, if not avoided, could result in minor or moderate injury.
is used to address practices not related to physical injury.
I
indicates additional information that is not related to physical injury.
1.3 Supplemental directives
Failure to follow these directives could result in property damage, serious injury, or death.
Do not alter this product beyond what is described in these technical specifications.
This product must comply with all applicable local or national codes, including the latest edition of the
following standards:
U.S.A.
• ANSI/NFPA70, National Electrical Code (NEC)
• ANSI/NFPA 1192, Recreational Vehicles Code
Canada
• CSA C22.1, Parts l & ll, Canadian Electrical Code
• CSA Z240 RV Series, Recreational Vehicles
2
EN
Coolers
1.4 General safety messages
Failure to obey the following warnings could result in death or serious injury:
• ELECTRICAL SHOCK HAZARD. Do not immerse the product in water, or use it in an area that is excessively
muddy.
• Do not use the cooler for any purpose other than as a mobile cooling device.
FALL HAZARD. Do not stand on the cooler. Doing so could damage the unit or cause minor to
moderate injury.
Failure to obey the following notices could result in property damage:
• Keep sand or dirt away from the cooling system ventilation area.
• Do not leave the cooler on the deck of a boat for an extended period. Salt water damage to the cooling
system, electronics, or metal hardware could occur.
• Do not expose the cooler to extreme heat.
• Only use mild soap and water to clean the cooler.
• Do not use a DC extension cord.
• Do not use a power strip or two-way splitter.
• Do not use power cord adapters of any kind other than those provided by the manufacturer.
• Do not use ice cubes or fill the cooler with water. If ice does accumulate at the bottom of the cooler, defrost
the unit and use the drain plug to drain the water.
• Do not modify the unit in any way.
• Do not place hot materials (75 °F or higher) in the cooler. Allow materials to cool (50 °F or less) before
placing them inside the cooler.
• Do not tip or store the cooler at an angle greater than 30° for extended periods. Compressor oil
contamination of the cooling system could occur.
• Allow 2–4 inches of space around the cooler at all times for proper ventilation of the cooling system.
• The cooler must be secured at all times using straps or a mounting plate, especially in mobile applications.
2 GENERAL INFORMATION
I
Refer to the following for general information regarding CF and CFX series coolers.
CF series:
• Emergency override will cause all contents to freeze.
• The degree variance for cooler operation is 3 °F average, and 5 °F maximum.
• All coolers prioritize 120 VAC over 12 VDC or 24 VDC.
CFX series:
• USB chargers are 5 VDC, 0.5 amp.
• All new coolers are shipped with a 12', 12 VDC cord.
• The CFX wireless display has a range of 20'.
• All coolers prioritize 120 VAC over 12 VDC or 24 VDC.
• If the ambient temperature is above 90 °F, the cooler will not reach the minimum temperature.
• These coolers do not include an auto-defrost function. The user must manually defrost the cooler.
3
EN
Coolers
3 SPECIFICATIONS
3.1 Temperature ranges
Series In box temperature range Ambient temperature range
CF series 0 °F–50 °F 61 °F–109 °F
CFX series -8 °F–50 °F 61 °F–109 °F
3.2 Storage and empty weight
Model Storage Empty weight
CF-18 0.7 cu. . 27.0 lbs.
CF-25 0.9 cu. . 26.5 lbs.
CF-35 1.1 cu. . 33.0 lbs.
CF-40 1.3 cu. . 37.0 lbs.
CF-50 1.7 cu. . 44.0 lbs.
CF-80 2.8 cu. . 62.0 lbs.
CF-110 3.7 cu. . 73.0 lbs.
CFX-28 0.9 cu. . 29.0 lbs.
CFX-35 1.1 cu. . 39.0 lbs.
CFX-40 1.4 cu. . 41.0 lbs.
CFX-50 1.8 cu. . 45.0 lbs.
CFX-65W 2.2 cu. . 49.0 lbs.
CFX-65DZ 1.8 cu. . 51.0 lbs.
CFX-75DZ 2.6 cu. . 68.3 lbs.
CFX-95DZ 3.0 cu. . 70.6 lbs.
CFX-100 3.3 cu. . 70.6 lbs.
