Sida 1/32

SANITATION

TOILETS

4500/4600/4700/4800

4000 Series

Operation Manual ...............1

Série 4000

Manuel d’utilisation ..............17

Toilets

NORTH AMERICAN ADDRESS INFORMATION

U.S.A. & CANADA

Service Oﬃce

Dometic Corporation

13128 St. Rte. 226

Big Prairie, OH 44611

Service Center & Dealer

Locations

Refer to “7 Customer Service” on

page 16.

Read these instructions carefully. These instructions MUST stay with this product.

CONTENTS

1 Explanation of symbols and safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2 Intended use ............................................................ 4

3 Operation ............................................................... 4

4 Maintenance ............................................................ 7

5 Troubleshooting .......................................................... 9

6 Disposal ................................................................16

7 Customer Service .........................................................16

8 Limited warranty ..........................................................16

Toilets

1 EXPLANATION OF SYMBOLS AND SAFETY INSTRUCTIONS

This manual has safety information and instructions to help you eliminate or reduce the risk of

accidents and injuries.

1.1 Recognize safety information



This is the safety alert symbol. It is used to alert you to potential physical injury hazards.

Obey all safety messages that follow this symbol to avoid possible injury or death.

1.2 Understand signal words

A signal word will identify safety messages and property damage messages, and will indicate the

degree or level of hazard seriousness.

indicates a hazardous situation that, if not avoided, could result in death or

serious injury.

indicates a hazardous situation that, if not avoided, could result in minor or

moderate injury.

is used to address practices not related to physical injury.

indicates additional information that is not related to physical injury.

1.3 Supplemental directives



Read and follow all safety information and instructions to avoid possible injury or death.

Read and understand these instructions before use and maintenance of this product.

Incorrect operation and maintenance of this product can lead to serious injury.

The installation must comply with all applicable local or national codes, including the

latest edition of the following standards:

U.S.A.

• ANSI/NFPA70, National Electrical Code

(NEC)

• ANSI/NFPA 1192, Recreational Vehicles

Code

• ABYC guidelines for marine installations

Canada

• CSA C22.1, Parts l & ll, Canadian Electrical

Code

• CSA Z240 RV Series, Recreational

Vehicles

1.4 General safety messages

Failure to obey the following warnings could result in property damage, serious

injury, or death:

• This product must be installed and serviced by a qualiﬁed service technician.

• Do not modify this product in any way. Modiﬁ cation can be extremely hazardous.

• FLOOD HAZARD:

• Before beginning work on this product, be sure that all electrical power to the unit has

been turned oﬀ and that seacocks are in the closed or oﬀ position.

• For toilets connected to any through-the-hull ﬁttings: always close seacocks when the

toilet is not in use (even if boat is unattended for a brief period).

• Instruct all passengers on how to close valves when the toilet is not in use.

• For toilets using fresh water for ﬂushing, disconnect any shoreside or municipal water

connections when the boat or RV is unattended for any length of time.
