Auditcon
®
Series Lock
Alarm Interface Adapter Kit
P/N 301040
The Kaba Mas Auditcon Series Combination Lock has an optional switch-
ing function that provides the same function as a duress alarm switch.
This duress alarm switching function operates with the same electrical
voltages and currents normally used with mechanical combination locks
having distress alarm switches.
This kit adds a duress alarm switch to the Auditcon Series combination
lock. The switching function is accessible through a 3 pin connector on
the Auditcon Series Alarm Interface Adapter. The kit consists of the
Adapter and a Duress Alarm Cable.
Installation
Adapter Assembly (P/N 302006)
The Adapter Assembly is installed by plugging the 3 wire cable, with
toroid, into the connector on the back of the Auditcon Series lock. The
Adapter is then mounted on the inside of the container near the lock
using the double sided mounting tape provided on the Adapter. The at-
tached cable should be routed neatly to prevent damage to the lock or
the Adapter.
Duress Alarm Cable (P/N 302018)
The Duress Alarm 48” Cable will be used to make a connection to your
alarm system. It is plugged into the 3 pin connector on the Adapter. Its
color coding and function is as follows:
OrangeCOMCommon
RedN/ONormally Open Contacts, close when the Silent Du-
ress PIN is dialed.
BrownN/CNormally Closed Contacts, open when the Silent Du-
ress PIN is dialed.
The Duress contacts are rated 30 Vac/Vdc, 2A, power limited source.
The alarm switch resets when the lock is powered up for the next opera-
tion.
P/N 300.047 Rev. D - 07/06
