DORMA Solutions

• Built-insensorwithlocaland/orremotealarmactivation

• Highlyvisible statusindicator(local)lightpanelRed/Green

• Built-inBondAlertSensor(BA)feature

• Drycontactrelayswitching(SPDTandDPDT)forlocal

and/orremotealarmmonitoring

• Autosensingvoltagefrom12to24VDC

• Upto1200lb(540kg)holdingforce

• Lowvoltagedetection

• Nuisancedelayfeaturetoaccommodateaccidental

triggering

• MOVsurgeprotection

• 628BrushedAnodizedAluminumlockbodynish

Listings & Approvals

• UL/CULlistedundertheircontinuingreinspectionprograms

andconformstostandardsUL10C,GWXT,andFWAX

positivepressureretesting,3hourreratedpending

• ANSI/BHMA156.23,Grade1pending

• CSFMpending

• ContributestoU.S.GreenBuildingCouncil,LEED

®MR

Credits2.14.1,4.2,and5.1

Optional Mounting Accessories

•Spacers

• Anglebrackets

• bracketsL

• Fillerbars

• Powersupply

• Keyswitch

• Externalsounder

EML310EW Single Outswinging Perimeter Doors

DORMA EML310EW early warning

electromagnetic locks detect

attempted forced entry through

a locked door.

Whenanintruderattemptstogainaccessintoabuilding,the

EML310EW'sbuilt-insensoractivatesalocaland/orremote

alarmpriortotheintegrityofthedoorbeingcompromised—

wellbeforethebreak-inhasoccurred.

Analarmintheimmediatelocationwillwardoffwouldbe

thievesbeforetheyhaveachancetogainaccess.Thelightpanel

provideshighlyvisibleinformationrelatedtothestatuschanges

ofthedoor.Forexample,itworksasastatusindicatorwhenthe

doorissecureornotiesifanattemptedbreak-inhasoccurred.

EML310EW DORMA

Electromagnetic Locks

Speciﬁcations EML310EW

HousingDimensions 2-1/8"D×2-7/8"H×10-13/16"L

(54mm×73mmx275mm)

Armature

PlateDimensions

5/8"D×2-3/8"H×7-7/16"L

(16mm×60mm×189mm)

Voltage Autosensingvoltage12to24VDC

Tolerance±10%

Power/Current

Requirements

Max0.58A@12VDC

Max0.29A@24VDC

HoldingForce Upto1200lb(540kg)lb

OperatingTemperature Circuitboardoperatingtemperature

14ºFto140ºF(–10ºCto60ºC)

NOTE:DORMArecommendsframereinforcementandourltered,

regulatedDCvoltagePS500Seriespowersupplies.

Function Function Descriptions

NuisanceDelay Thisfeatureisdesignedtoreduceaccidentaltriggering.

Apulltothedoorwithaminimumof55lbofforcechangesthelightpanelfromgreentoredandtriggersthe

localalarmrelay.

Ifthepressureiswithdrawnwithin4seconds,thesystemwillreturntonormal.

30SecondAlarmPeriod Ifpressureonthedoorismaintainedformorethan4seconds,theremotealarmrelaywillactivate,thelocal

alarmrelayremainsonandthelightpanelcontinuestoashred.

After30seconds,thelocalandremotealarmrelaywillreturntonormal,butthelightpanelwillcontinueto

blinkindicatinganattemptedbreak-inhasoccurreduntilreset.

LightPanel Thisfulllengthfeatureisahighlyvisibleredandgreenstatusindicator.

SupplementarySounder Anexternalalarmdevicemaybeconnectedtopulseduringthe4secondnuisancedelayandsoundsteady

duringthe30secondremotealarmperiod.

NOTE:AllinstallationsmustbeapprovedbytheLocalAuthorityHavingJurisdiction(AHJ)

How to Order EML310EW Series

Series

310EW

EML

Model

310EW

Single Door w/ Early

Warning Sensor, 1200 lb

Electromagnetic

Locks

FB12

FB14N

FB14

FB15

FB11

FB25

FB714

FB715

1/8"H × 3/4"W × 10-1/2"L —

AB22

AB21

AB20

AB13

AB11

628

Mounting Brackets1

Fillers/Spacers1

628 Clear Anodized

Aluminum

EML

1/4"H × 3/4"W × 10-1/2"L —

1/2"H × 5/8"W × 10-1/2"L —

1/2"H × 3/4"W × 10-1/2"L —

5/8"H × 3/4"W × 10-1/2"L —

1/4"H × 3/4"W × 21"L —

1/2"H × 5/8"W × 21"L —

1/2"H × 3/4"W × 21"L —

5/8"H × 3/4"W × 21"L —

1/2"H × 3/4"W × 9"L —

5/8"H × 3/4"W × 9"L —

1/2"H × 1-1/2"W × 21"L —

5/8"H × 1-1/2"W × 21"L —

—

FB22

FB24N

FB24

BSS24

BSS25

— 1"H × 1"W × 10-1/2"L

— 1-1/2"H × 1"W × 10-1/2"L

— 1-1/2"H × 1-1/4"W × 10-1/2"L

— 1"H × 1"W × 21"L

— 1-1/2"H × 1"W × 21"L

— 1-1/2"H × 1-1/2"W × 21"L

APH10

Armature Plate Holders1

GDB14

GDB16

Glass Door Brackets

— 3/4"

— 1/2"

AMB300

AMB275

AMB225

Armature Bolts

2-3/4"–3" Doors —

2-1/4"–2-3/4" Doors —

1-3/4"–2-1/4" Doors —

EML310EW —

LB20

TJ10

— 2-1/2"H × 2"W × 21"L

— Top Jamb Bracket

AB12

—

1. Specify 628 or 695 ﬁnish, except FB11/LB20/CMB10 available in 628 only.

CMB10 — Conduit Mounting Bracket

Finish

DORMA

Electromagnetic Locks

EML310EW

DORMAalsooffersacompletelineofElectromagneticLocks,ElectricStrikes,DoorControls,PowerSupplies,Switches,Keypads

&Readers,ExitDevices,Systems&DoorHardware.

DORMA Americas

www.dorma-usa.com

DORMA Architectural Hardware

DORMADrive,DrawerAC

Reamstown,PA17567-0411

Telephone:(800)523-8483

Facsimile:(800)274-9724

E-mail:archdw@dorma-usa.com

DORMA Canada

1680CourtneyParkDrive,Unit13

Mississauga,OntarioL5T1R4

Telephone:(800)387-4938

Facsimile:(905)670-5850

E-mail:sales@dormacanada.com

DORMA Mexico, S. de R.L. de C.V.

Astrónomos28,Col.Escandón

México,D.F.11800

Del.MiguelHidalgo

Telephone:(52+55)5272-6937

Facsimile:(52+55)5272-6948

E-mail:operacion@dorma.com.mx

Subjecttochangewithoutnotice6.12CT2.5MUSA07000410
