Subject to change without notice
7-7/8"
(200)
7-7/8"
(200)
69 -5/16"
(1760)
35-7/16"
(900)
40-3/16"
(1020)
56 -"11/16
(1440)
35-7/16"
(900
)
HSB-M01
51-3/16"
(1300)
HSB-M01 sensor barriers
Moderate
Moderate units offer
tailgating monitoring.
Standard unitsHSB-M01
Note: Description of single unit
Interlock height40-3⁄16" (1020)
Interlock length 69-5⁄16" (1760)
Passage width
35
-7⁄16"
(900)
Total width
51
-3⁄16
" (1300)
Housing, base columns,
guiding elements
AISI 304 stainless steel with satin finish.
ADA compliance36" (915) width available.
Barrier elements
Two door leaves made of curved AISI 304, Ø1-1/16" (26.9) stainless steel
tubes with Ø 3/8" (10) vertical struts, upper edge
35
-7⁄16
" (900).
Swinging area monitored by a light grid.
SecurityPassage area monitored by basic sensor system with a compact
installation length (basic level of single passage monitoring in
both directions)
FinishStainless steel semi-gloss smooth finish.
SafetyLow energy drive with energy content less than 1.18 lb/ft.
FunctionType 2-power assisted motion; two servo-positioning drives/
electrically controlled in both directions.
DrivesIntegrated in the swing tube.
Operating modesOptical.
Normally closed.
Normally opened. (Barriers close on tailgate event.)
Electrical equipmentControl system and power supply integrated in the unit.
Power supply110 – 230 VAC, 50/60 Hz. 368 VA
Standby power
consumption
17 VA
Standard adjustment in
case of power failure
Door leaves move freely.
InstallationDowelled on finished floor level FFL.
Suitable for outdoor installation.
Protection classesHousing IP54, components conducting supply voltage IP54.
Entrance systems
