Sida 1/6

INSTALLATION

RCI 8310 / 8320

ELECTROMAGNETIC LOCKS

www.dormakaba.us • Phone: 1.800.265.6630 • Fax: 1.800.482.9795 • E-mail: sales_RCI@dormakaba.com

IS8310-20-V1-2

PCN19025

R07-20GR-1

1. Mount the electromagnetic lock to the door frame as outlined on

the installation template included with the product.

NOTE: During installation of the armature plate to the door it

is essential that the armature plate remains movable. The

armature plate must be allowed to pivot on the center-mounting

bolt to allow proper alignment with the magnet surface. If the

plate is not aligned with the magnet surface, the lock may lose

holding force or not lock at all .

The head of the armature mounting bolt ships with a rubber

washer affixed to it. This washer should project slightly beyond

the surface of the armature plate. This is to allow the washer to

expand when power is removed and break the air vacuum

between the plate and the magnet surface. If this washer is

removed or trimmed the lock will appear to have some holding

force even when power is removed.

For added safety, thread locking compound has been provided for

the armature plate bolt and the four captive electromagnetic lock

mounting screws.

WARNING: Improper installation, maintenance, inspection or usage

of the product or any related accessories or parts may cause the

electromagnetic lock, armature plate and associated hardware

to disengage and fall, causing serious bodily injury and property

damage. dormakaba Canada Inc. and/or dormakaba USA Inc. will

not be liable to the installer, purchaser, end user or anyone else for

damage or injury to person or property due to improper installation,

care, storage, handling, maintenance, inspection, abuse, misuse

or act of God or nature involving this product or any related

accessories or parts.

2. Route the power supply connecting wire through the door frame

and into the wire access hole in the top of the magnet housing.

Connecting wire should be of sufficient gauge for the lock being

installed and the distance being run.

Installation Instructions

PLEASE DELIVER ALL INSTALLATION INSTRUCTIONS TO

THE END-USER UPON COMPLETION OF THE INSTALLATION.

Pre-Installation Instructions

1. This product must be installed according to all applicable building

and life safety codes.

Due to the variety of mounting configurations available with this

product, a survey and assessment of the physical area in which

the product will be installed must be performed.

3. The door frame must be inspected and deemed structurally sound

prior to installation of the electromagnetic lock. The structural

integrity of the mounting surfaces must be strong enough to meet

or exceed the holding force of the product.

4. The product must be protected from potential damage due to

intruders or tampering.

5. The product should be installed in a location that will not hinder

or create a potential safety hazard to authorized personnel

accessing the protected area.

6. Because electromagnetic locks are used in a variety of applications

and different door frame configurations, an experienced installer

with knowledge of this product must make a determination of the

optimal mounting method for this specific application.

7. The components, hardware, installation instructions and mounting

template included with this product are intended for use on

outswinging doors.

8. Do not install this product on the exterior of buildings.

9. Do not use as a doorstop. This will void warranty.

10. Separate accessories, must be used in the following applications:

• Inswinging doors

• Narrow head jamb situations or center-hung doors

• Wherever there is insufficient space on the door

frame header to mount the lock

• Glass or Herculite doors that do not have a door frame

• Hollow metal or wood frames where the door stop is

not thick enough to allow the product to be installed

• Wherever an obstruction in the door prevents

installation of the armature plate at a proper height

• Doors that do not permit the armature plate to be

mounted low enough to meet the magnet surface

Refer to the page 5 & 6 Product Accessories Guide, for further

information. Accessories may impact holding force.

11. Installation of this product should be done by an experienced

installer with knowledge of this product.

NOTE: It is highly recommended that thread locking compound

be applied to all screws during installation to reduce chance of

screws loosening over extended time.
