Sida 1/2

Red POSITIVE

(“+”) clamp

connects to

positive

battery

terminal

Black NEGATIVE (“

”) clamp

connects to negative battery

terminal or to

metal part of car

(block, cylinder, etc)

7. Correct polarity must be established before proceeding. Re-check your

connections before starting your engine. If the clamps are reversed,

disconnect the jump-start clamps from the vehicle’s battery and redo

steps 5 and 6 in this procedure.

8. Before starting the engine, make sure the jump-starter and the cables

are clear of belts and fans.

9. Crank the engine for 4 seconds or until it starts, whichever is rst.

10. Remove the red positive (+) clamp and then the black negative (–)

clamp from the vehicle.

11. Store the jump-start clamps in the appropriate holder on each side of the

jump-starter.

IMPORTANT

If you keep the jump-starter in storage, the battery will discharge over time.

Remember to recharge the battery every three months to keep the jump-

starter operational.

7. Maintenance

Routine maintenance is required to keep your Duracell

jump-starter

operating properly. Occasionally clean the exterior of the unit with a damp

cloth to remove the accumulated dust and dirt.

WARNING: SHOCK HAZARD

Disconnect all sources of AC power and DC power before performing any

type of maintenance.

► Battery maintenance

All rechargeable batteries gradually discharge when left standing, and you

need to recharge them periodically to maintain maximum battery capacity.

The AC battery charger supplied with the jump-starter is designed to regulate

the charging process, ensuring that the battery is always fully charged but

never overcharged. To ensure safe recharging and maximum battery life,

recharge the jump-starter only with the supplied charger or approved battery

chargers.

CAUTION

Due to inherent self-discharge, lead acid batteries must be charged at

least every 3 months, especially in a warm environment. Leaving a battery

in a discharged state, or not recharging every 3 months, may result in

permanent battery damage and poor jump-starting performance.

CAUTION

Do not attempt to recharge the jump-starter battery if it is frozen. Gradually

warm the frozen battery to 32 °F (0 °C) before recharging.

Portable Emergency Jumpstarter

1. Features

1: Emergency light

on/off button

2: Fuel gauge button and

USB on/off switch

turns

on the fuel gauge indicator.

Turns on power to the USB

charge port.

3: LED fuel gauge/battery

level indicator shows battery

fuel level.

4: USB charge port

and indicator light.

Supplies up to 2.1 Amps

of charging power for

your USB devices.

5: 12V DC power socket

powers 12V DC devices and

appliances. It is also used to

recharge the jump-starter’s

internal battery.

6: Emergency light provides

bright LED illumination in dark

locations.

7: Negative jump

starting clamp

connects to the

engine

block

(see Section 6).

8: AC battery charger

quickly recharges the jump-

starter’s internal battery from

a standard AC wall outlet;

stores in compartment on

bottom of unit.

9: Positive jump starting

clamp

connects to the

positive

battery terminal (see Section 6)

2. Important Safety Information

Misusing or incorrectly connecting the Duracell

Jump-starter may damage

the equipment or create hazardous conditions for users. Read the following

safety instructions and pay special attention to all Caution and Warning

statements in the guide.

• Warnings identify conditions that may result in personal injury or loss of life.

• Cautions identify conditions or practices that may damage the unit or other

equipment.

IMPORTANT

For general usage warnings and cautions, please see Section 9:

Warnings and Cautions on Page 2 of this manual. Please read these

items carefully before using this jump-starter.

WARNING: ELECTRICAL SHOCK HAZARD

The jump-starting clamps may spark if touched together. Always keep the

clamps in their storage holsters when they are not being used.

3. Charging/Recharging the Jump-starter

► Charging before rst use

IMPORTANT

Prior to using the jump-starter for the rst time, ensure that the battery of

the jump-starter is fully charged. If the battery has been fully discharged,

charging/recharging with the AC battery charger may take up to 12 hours.

Charging / recharging with the AC battery charger

Recharging with the AC battery charger is a true “plug-in-and-forget” charging

method. We recommend leaving the AC battery charger connected when the

jump-starter is not in use.

1. Disconnect any USB and 12V DC appliances from the DC power outlets.

2. Remove the AC charger from the storage compartment under the unit.

3. Plug the AC battery charger into a standard AC wall outlet. Plug the

other end of the charger into the 12V socket of the jump-starter. The

“Red” LED on the charger will light up when battery is charging

4. Recharging time should be approximately 12 hours if the jump-starter

battery is fully discharged. “Green” LED lights up on charger when

battery is fully charged.

IMPORTANT

The 12-hour charging time for the jump-starter assumes that there is 120V

AC at the AC wall outlet. If the voltage is less than 120V AC, it may take

more than 12 hours to fully recharge the jump-starter If, after 12 hours

of charging, the Battery Status LED remains red, continue to charge the

unit for another 12 hours. The unit will be ready for use even if the Battery

Status LED remains red.

IMPORTANT

If you keep the jump-starter in storage, the battery will discharge over time.

Remember to recharge the battery every three months to keep the jump-

starter operational.

Note: Once fully charged, the charging current automatically reduces to a

maintenance charge mode, and the jump-starter may be left permanently

connected to the AC battery charger.

4. Checking the Jump-starter’s Battery Level

To check the battery’s charge level, press the Fuel Gauge button. The LED

lights will illuminate and display the current level of available battery power.

When all four lights are lit, this indicates that your Jump-starter is fully

charged. It is recommended to maintain a full charge on the Jump-starter at

all times for optimal jump starting and device charging.

IMPORTANT

Your jump-starter will perform best when its battery is fully charged. If the

LED Fuel Gauge shows less than 100% charge, it is recommended to fully

recharge your battery (see Section 3: “Charging/Recharging the Jump-

starter’s Battery” above).

Note: Battery Fuel Gauge status is only accurate when the jump-starter

has been disconnected from all appliances and all charging sources for 15

minutes.

5. Using The Jump-starter’s Light / Power Ports

► Using the built-in light

The Duracell

Jump-starter has a built-in emergency light to provide a safe,

bright work light on the roadside and in other outdoor environments.

1. Push the “Emergency Light” button to turn on the LED light.

2. Position the jump-starter so that the light illuminates your work area.

3. When done, push the “Emergency Light” button again to turn the LED

light off.

► Using the USB port

The USB port provides up to 2.1 Amps of power to charge cell phones,

smartphones, tablets and other devices.

To charge USB devices:

1. Connect your USB device (smartphone, tablet player, etc.) to the USB

port using the USB cable supplied with your device.

2. Push the “On/Off” button.

3. Charging will start and up to 2.1 Amps of current can be supplied by the

port. The USB device controls the amount of current supplied. The

jump-starter never “pushes” more than required by the devices.

4. Push the “On/Off” button again when done to turn the USB port off.

► Using the 12V DC power socket

The jump-starter can operate 12V DC appliances that draw 11A or less from

a 12V DC power outlet or from a vehicle’s lighter socket.

CAUTION: EQUIPMENT DAMAGE

The DC power outlet does not automatically switch off when the internal

battery is discharged. Check the battery status periodically to prevent total

battery discharge.

Note: The fewer watts a 12V DC appliance draws, the longer the jump-

starter will operate before recharging is required.

To operate a 12V DC appliance:

5. Open the protective cover on the jump-starter’s DC power socket.

6. Plug the 12V DC appliance into the DC power outlet on the front panel of

the unit, and turn the 12V DC appliance on (if required).

7. Fully recharge the jump-starter as soon as possible after each use.

8. As the DC power socket is internally wired directly to the jump-starter’s

battery, extended operation of a 12V DC appliance may result in

excessive battery discharge. See “Caution: Equipment Damage” above.

6. Jump-Starting A Vehicle’s Engine

You can use the Duracell

jump-starter with the supplied jump-start cables to

jump-start a vehicle or boat engine that has a 12V starting battery.

WARNING: FIRE HAZARD

Never allow jump-start cables’ red and black clamps to touch each other

or another common metal conductor. This could cause damage to the unit

and/or create a sparking/explosion hazard.

WARNING: FIRE HAZARD

Jump-start cable clamps’ connection to the vehicle’s battery terminals must

be positive to positive (red clamp to battery “+”) and negative to engine

block. A reverse polarity connection (positive to negative) may cause

damage to the unit and/or create a sparking/explosion hazard.

WARNING: FIRE HAZARD

Do not crank the engine for more than 4 seconds. The jump-start feature is

designed for short term operation only. Operating the jump-start feature for

more than 4 seconds may cause damage to the unit. Allow the jump-starter

to cool down for at least 3 minutes after each jump-start.

► To jump-start a vehicle engine:

1. Turn OFF the vehicle or boat ignition and all accessories.

2. Engage the park or emergency brake and place the transmission in park

for an automatic or neutral for a manual.

3. If jump-starting a boat engine, purge the engine compartment and bilge

of all fumes.

4. Position the jump-starter on a at, stable surface near the battery and

away from all moving parts of the engine.

5. Connect the red positive (+) clamp of the cables to the positive (+)

terminal of the engine battery. The battery’s positive terminal is usually

larger in diameter than the negative terminal. In most vehicles, the

battery’s positive terminal has a red wire connected to it.

6. Connect the black negative (–) clamp of the cables to the engine block,

cylinder head, or other stationary heavy metal part of the motor.

Produktspecifikationer

Varumärke:	Duracell
Kategori:	Accu
Modell:	Jump-Starter 750
Vikt:	3500 g
Bredd:	156 mm
Djup:	280 mm
Höjd:	170 mm
Batterikapacitet:	9000 mAh
Batteriteknik:	Slutna blybatterier (VRLA)
Produktens färg:	Black, Red
Batterispänning:	12 V
Antal batterier medföljer:	1 styck
