Eaton 5E900UD Bruksanvisning

Eaton avbrottsfri strömförsörjning (UPS) 5E900UD

Läs gratis den bruksanvisning för Eaton 5E900UD (19 sidor) i kategorin avbrottsfri strömförsörjning (UPS). Guiden har ansetts hjälpsam av 4 personer och har ett genomsnittsbetyg på 4.3 stjärnor baserat på 2.5 recensioner. Har du en fråga om Eaton 5E900UD eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/19

Eaton 5E



Advanced User Guide



DSD-5E2206



English



5E550I

5E700I

5E700D

5E700F

5E700B

5E700UI

5E700UD

5E700UF

5E700UB

5E900UI

5E900UD

5E900UF

5E900UB

5E1200UI

5E1200UD

5E1200UF

5E1200UB

5E1600UI

5E1600UD

5E1600UF

5E1600UB

5E2200UI

DSD-5E2206

1 Special symbols ................................................................................................................ 1

2 Introduction ...................................................................................................................... 2

2.1 Environmental protection ........................................................................................................................ 2

2.2 Benefits...................................................................................................................................................... 3

3 Presentation...................................................................................................................... 4

3.1 Standard installation ................................................................................................................................4

3.2 Rear panel.................................................................................................................................................. 5

4 Installation ........................................................................................................................ 6

4.1 Inspecting the equipment ........................................................................................................................ 6

4.2 Recommended positions.......................................................................................................................... 7

4.3 UPS connection......................................................................................................................................... 7

4.4 USB COM port (optional) .......................................................................................................................... 9

4.5 Register warranty...................................................................................................................................... 9

5 Operation .......................................................................................................................... 9

5.1 Start-up and normal operation ................................................................................................................ 9

5.2 Starting the UPS on battery.................................................................................................................... 10

5.3 UPS shutdown......................................................................................................................................... 10

5.4 Operating modes .................................................................................................................................... 10

5.5 Return of AC input power ....................................................................................................................... 11

6 UPS maintenance............................................................................................................ 11

6.1 Equipment care....................................................................................................................................... 11

6.2 Storing the equipment............................................................................................................................ 12

6.3 Recycling the used equipment............................................................................................................... 12

7 Troubleshooting.............................................................................................................. 13

7.1 Service and support................................................................................................................................ 14

8 Specification and technical characteristics................................................................... 14

8.1 Electrical input ........................................................................................................................................ 14

8.2 Electrical output...................................................................................................................................... 15

8.3 Battery ..................................................................................................................................................... 15

8.4 Environmental and safety ...................................................................................................................... 16

9 Glossary ........................................................................................................................... 17



DSD-5E2206

1 Special symbols

The following are examples of symbols used on the UPS or accessories to alert you to importantinformation:

DANGER: Dangerous voltage levels are present within the UPS. The UPS has its own internal power

source (the battery). Consequently, the power outlets may be energized even if the UPS is disconnected

from the AC power source.

Important instructions that must always be followed.

CAUTION: Batteries present a risk of energy or electrical shock or burn from high short circuit current.

Observe proper precaution. Batteries may contain HIGH VOLTAGE and CORROSIVE, TOXIC and

EXPLOSIVE substances.

Information, advice, help.

Read the documentation provided.

Disconnect input plug.

Before maintenance, first shut down the UPS then disconnect the AC power source, internal and

external batteries then discharge capacitors by pressing the ON button and wait 5 minutes.

This equipment should only be used in a dry indoor environment.

Operating range of temperature.

Operating range of humidity.

The UPS and their batteries must be kept in a ventilated place.



Produktspecifikationer

Varumärke:	Eaton
Kategori:	avbrottsfri strömförsörjning (UPS)
Modell:	5E900UD
Vikt:	5300 g
Bredd:	100 mm
Djup:	288 mm
Höjd:	148 mm
Certifiering:	EN IEC 62040-1:2019; EN 62040-2:2006; IEC 62040-2: 2016, IEC 62040-3: 2021; CE; EAC; UKCA; Cm; Ukr
Uteffekt:	480 W
Automatisk omstart:	Ja
UPS-topologi:	Linjeinteraktiv
Automatiskt batteritest:	Ja
Produktens färg:	Svart
Kontrolltyp:	Knappar
Formfaktor:	Tower
Ingångsfrekvens:	50/60 hz
Effekt skyddsfunktioner:	Over voltage, Under voltage
Temperatur vid drift:	0 - 40 ° C
Hållbarhetscertifiering:	Low Voltage Directive (LVD), RoHS, WEEE
Strömkälla av typen:	AC
Ljudnivå Lc IEC:	25 dB
Antal USB 2.0 anslutningar:	1
USB-port:	Ja
Antal uttag AC:	2 AC-utgångar
Uppfyller hållbarhetskrav:	Ja
Hörbart larm:	Ja
Uteffekt kapacitet (VA):	0.9 kVA
Inmatning spänning (min):	220 V
Inmatning spänning (max):	240 V
Utgång, driftspänning (min):	220 V
Utgång, driftspänning (max):	240 V
Hörbara alarmlägen:	Batteribyte
Kallstart:	Ja
AC försäljningsställen:	Typ F
