Eaton 9PX 2000 Bruksanvisning

Eaton avbrottsfri strömförsörjning (UPS) 9PX 2000

Läs gratis den bruksanvisning för Eaton 9PX 2000 (46 sidor) i kategorin avbrottsfri strömförsörjning (UPS). Guiden har ansetts hjälpsam av 3 personer och har ett genomsnittsbetyg på 5.0 stjärnor baserat på 2 recensioner. Har du en fråga om Eaton 9PX 2000 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/46

ENGLISH

9PX 5000

9PX 6000

9PX 6000 G

9PX EBM 180V

Installation

and user manual

Service and support:

Call your local service representative

5-6kVA US_EN

Page 2

5-6kVA US_EN

SAVE THESE INSTRUCTIONS. This manual contains important instructions

that should be followed during installation and maintenance of the UPS and batteries.

The 9PX models that are covered in this manual are intended for installation

in an environment within 0 to 40°C, free of conductive contaminant.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will

be required to correct the interference at his own expense.

Certication standards

• Safety: IEC/EN 62040-1 / Ed.1: 2008.

UL 1778 4th edition

• EMC: IEC/EN 62040-2 / Ed.2: 2006.

FCC part 15 Class A.

• Performance: IEC/EN 62040-3 / Ed.2.0: 2011.

• IEC 61000-4-2 (ESD): level 3.

• IEC61000-4-3(Radiatedeld):level3.

• IEC 61000-4-4 (EFT): level 4.

• IEC 61000-4-5 (Fast transients): level 4.

• IEC61000-4-6(Electromagneticeld):level3.

• IEC61000-4-8(Conductedmagneticeld):level4.

Special symbols

The following are examples of symbols used on the UPS or accessories to alert you to important

information:

RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric shock symbol.

Important instructions that must always be followed.

Do not discard the UPS or the UPS batteries in the trash.

This product contains sealed lead acid batteries and must be disposed as it's explain in this manual.

For more information, contact your local recycling/reuse or hazardous waste center.

This symbol indicates that you should not discard waste electrical or electronic equipment (WEEE)

in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center.

Information, advice, help.

Refer to the user manual of UPS accessories.

SAFETY INSTRUCTIONS

Produktspecifikationer

Varumärke:	Eaton
Kategori:	avbrottsfri strömförsörjning (UPS)
Modell:	9PX 2000
Vikt:	27900 g
Bredd:	440 mm
Djup:	605 mm
Höjd:	86.5 mm
LED-indikatorer:	Status
Certifiering:	CE, cULus, NOM
RS-232 port:	1
Uteffekt:	1800 W
Automatisk omstart:	Ja
Effektivitet:	91 %
Rackkapacitet:	2U
Batteriteknik:	Slutna blybatterier (VRLA)
Överspänningsskydd:	Ja
UPS-topologi:	Dubbelkonvertering (Online)
Seriellt gränssnitt:	Ja
Utspänning THD:	3 %
Vågform:	Sinus
Kabellängd:	2.44 m
Produktens färg:	Svart, silver
bruksanvisning:	Ja
Skärmtyp:	LCD
Förpackningstyp:	Låda
Formfaktor:	Rack / Torn
Ingångsfrekvens:	50/60 hz
Antal LAN (RJ-45) anslutningar:	2
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	0 - 35 ° C
Intervall för relativ operativ luftfuktighet:	0 - 96 %
Fuktighet (förvaring):	0 - 96 %
Hållbarhetscertifiering:	RoHS, ENERGY STAR
Kabel inkluderad:	RS-232, USB cable
Ljudnivå Lc IEC:	47 dB
Webbaserad adminstraion:	Ja
Antal USB 2.0 anslutningar:	1
USB-port:	Ja
Antal uttag AC:	7 AC-utgångar
Svarstid (medel):	0 ms
Altitud vid drift:	0 - 3000 m
Uteffekt kapacitet (VA):	2 kVA
Inmatning spänning (min):	100 V
Inmatning spänning (max):	144 V
Utgång, driftspänning (min):	100 V
Utgång, driftspänning (max):	125 V
Utfrekvens:	50/60 hz
Inström THD:	3 %
Kallstart:	Ja
Hot-swap batteri:	Ja
AC försäljningsställen:	NEMA 5–20R, NEMA L5-20R
Uttag:	NEMA 5-20P
Överspänningsskydd funktioner:	Nätverk
Fäste:	Ja
