Z97M-PK

USER GUIDE

Version:1.0

40-012-EU4105

Z97M-PK

USER MANUAL

Preface

This publication, including all photographs, illustrations and software, is protected

any of the material contained herein, may be reproduced without written consent of

the author.

Version 1.0

Disclaimer

The information in this document is subject to change without notice. The manufac-

turer makes no representations or warranties with respect to the contents hereof

and specifically disclaims any implied warranties of merchantability or fitness for

any particular purpose. The manufacturer reserves the right to revise this publica-

tion and to make changes from time to time in the content hereof without obligation

of the manufacturer to notify any person of such revision or changes.

Trademark Recognition

Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.

MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel

Corporation.

Other product names used in this manual are the properties of their respective owners

and are acknowledged.

Federal Communications Commission (FCC)

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential instal-

lation. This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment onto an outlet on a circuit different from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Shielded interconnect cables and a shielded AC power cable must be employed with

this equipment to ensure compliance with the pertinent RF emission limits govern-

ing this device. Changes or modifications not expressly approved by the system’s

manufacturer could void the user’s authority to operate the equipment.

Produktspecifikationer

Varumärke:	ECS
Kategori:	moderkort
Modell:	Z97M-PK
Bredd:	244 mm
Djup:	220 mm
Antal HDMI-portar:	1
Hörlursutgångar:	1
Certifiering:	CE/FCC, ErP/EuP, WHCK
Maximalt internminne:	32 GB
Intel® Smart Response Technology:	Ja
Intel® Hyper Threading Technology (Intel® HT Technology):	Ja
Intel® InTru™ 3D-teknik:	Ja
Intel® Insider™:	Ja
Intel® Identity Protection Technology (Intel® IPT):	Ja
Ljudutgångskanaler:	7.1 kanaler
Intel® Rapid Storage Technology:	Ja
Komponent för:	PC
Kompatibla processorer:	Intel Celeron, Intel Pentium
Minnestyper som stöds:	DDR3-SDRAM, DDR3L-SDRAM
Antal minnesplatser:	4
BIOS-typ:	AMI
Obuffrat minne:	Ja
processortillverkare:	Intel
DirectX-version:	11.1
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	LGA 1150 (uttag H3)
Antal PS/2-portar:	2
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	4
RAID-nivåer:	0, 1,5, 10
Minnesplatser, typ:	DIMM
Minneskanaler:	Dubbla kanaler
Minnets hastigheter:	1066,1333,1600,1866,2133,2400 MHz
Max antal processorer:	1
USB 2.0 anslutning:	3
ATX strömkontakt (24-pin):	Ja
Fläktanslutning:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	2
BIOS minnesstorlek:	64 mbit
LAN-styrenhet:	Realtek RTL8111G
Wake-on-LAN förberedd:	Ja
Moderkort, chipsetfamilj:	Intel
Moderkortets chipset:	Intel® Z97
Moderkort formfaktor:	micro ATX
Kvalitet på VGA (D-Sub) porten:	1
Systembuss, hastighet:	5 GT/s
Uttag för mikrofon/linje in:	Ja
Intel® Turbo Boost Technology:	2.0
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® Quick Sync Video Technology:	Ja
Lagringsenhetsgränssnitt som stöds:	SATA III
Antal DVI-I anslutningar:	1
USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar:	1
Antal SATA III kontakter:	6
CPU-fläktsanslutning:	Ja
Antalet COM-anslutningar:	1
Clear CMOS knapp:	Ja
Chassits genomgångsanslutning:	Ja
Intel® Core i3/i5/i7/i9 serien:	i3-4xxx, i5-4xxx, i7-4xxx
Antalet parallella ATA-anslutningar:	1
EZ-anslutning:	Ja
