Sida 1/48
PELLKAMIN2 12
PELLET FIREPLACE
UK Installation, use and maintenance
809530 809550
809580
809560
2
ENGLISH
The undersigned company, EDILKAMIN S.p.A., with
registered office in Via Vincenzo Monti 47 - 20123
Milan (Italy) - Italian Tax ID code and VAT number
00192220192
Hereby declares, under its sole responsibility, that:
The product mentioned below complies with EU
Regulation 305/2011 and the harmonised EU standard
EN 14785:2006
PELLET FIREPLACE, bearing the
EDILKAMIN brand, known as PELLKAMIN2 12
SERIAL NO.: Rating plate reference
Performance declaration: (DoP - EK No. 176):
Rating plate reference
Moreover, the company hereby declares that:
PELLKAMIN2 12 complies with the requirements in the
following European Directives:
2014/35/EC - Low Voltage Directive
2014/30/EC - Electromagnetic Compatibility Directive
Safety information 4
Safety information 4
Dimensions 5
Dimensions 5
Technical data 7
Technical data 7
Unpacking 8
Unpacking 8
Packaging 10
Packaging 10
Installation (fume discharge, air intake) 12
Installation (fume discharge, air intake) 12
Connections on the terminal boards 15
Connections on the terminal boards 15
Fastening the product and the base (optional) 16
Fastening the product and the base (optional) 16
Fitting the components (according to the version)
Fitting the components (according to the version)
•
•
Pellet loading trapdoor 17
Pellet loading trapdoor 17
•
•
Ducted ventilation 18
Ducted ventilation 18
•
•
Frontal ventilation kit 21
Frontal ventilation kit 21
•
•
Pellet loading drawer 24
Pellet loading drawer 24
Notes on cladding 28
Notes on cladding 28
Fitting the inlet surround 29
Fitting the inlet surround 29
Instructions for use 30
Instructions for use 30
Maintenance 39
Maintenance 39
Troubleshooting 42
Troubleshooting 42
CONTENTS
NOTE
Pellkamin is available in four versions:
1. with ducted ventilation and a pellet loading trapdoor (see the fitting sections on “Ducted Ventilation” and “Load-
ing Trapdoor”)
2. with frontal ventilation and a pellet loading trapdoor (see the fitting sections on “Frontal Ventilation Kit” and
“Loading Trapdoor”)
3. with frontal ventilation and a pellet loading drawer (see the fitting sections on “Frontal Ventilation Kit and drawer”)
4. with ducted ventilation and a pellet loading drawer (see the fitting sections on “Pellet loading drawer” and
“Ducted Ventilation”)
This manual provides users with instructions on how to install and use all four versions. The numbers at the side of
the table of contents indicate the pages for that/those version(s).
The contents from page 5 to page 29 are meant for the
The contents from page 5 to page 29 are meant for the
installer
installer
