Sida 1/2

EA-IO7D V2

Indoor 7dBi Omni-direconal

Desktop Antenna

Edimax EA-IO7D V2 is a high performance 7dBi omni-direconal antenna to improve the wireless network signal

and coverage in your home and oce. The antenna is connected with a detachable stand which allows you to

relocate the antenna one meter away to a proper / higher posion to pick up stronger wireless signals. The

stand base is built in with strong magnet so users can aach it to any metal wall/paron/cabinet or surface.

Wireless signal and distance improvement

EA-IO7D increases the wireless coverage area when it is connected to a wireless AP/router. It also improve the

transmission range when the antenna is connected to a wireless adaptor.

7dBi high gain performance antenna

The antenna is exible to rotate 360°.

Universal RP-SMA connector for exible connecons

The antenna is not only compable with Edimax devices, but also with most wireless devices of RP-SMA

interface.

Signal transmission in all direcons

The antenna is omni-direconal so it transmits and receives signals from all direcons. It is the best soluon for a

radius coverage.

No soware or driver needed

All you have to do is to unscrew the original antenna from the device and replace with EA-IO7D onto the devices.

The antenna starts to work when placed to a proper posion.

FEATURES

• Complies with IEEE802.11b/g /n standards

• Provides 7dBi high gain antenna with desktop antenna stand

• Provides universal RP-SMA connector to t with most wireless device

• Aaches to any metal surface with the magnec relocaon stand

• Provides Omni-direconal antenna for radius coverage

Maximum performance, actual data rates, and coverage will vary depending on network condions and environmental factors. Pro t specicaons and design are subject to change without noce. duc

www.edimax.com

HARDWARE INTERFACE STANDARD & FREQUENCY BAND PEAK GAIN

7dBi RP-SMA detachable antenna

-SMA connector at antenna end RP

IEEE802.11b/g/n

-2500MHz 2400

7dBi

POLARIZATION ANTENNA SPEC DIMENSION

HPBW/ horizontal: 360 degree

HPBW/ vercal: 20~25 degree

VSWR (Voltage Standing Wave

Radio) : 2.0 : 1 Max

Impedance: 50 Ohms

Power handling 2 W (c w)

Antenna : OD 13 x

280mm

NETWORK SETUP DIAGRAM AND RELATED PRODUCTS

An example of EA-IO7D V2 applicaon:

• Connect to a wireless 802.11b/g /n device (access point , router or adapter…) with RP-SMA

connector

• Adjust the antenna angle to pick up strongest signal

RADIATION PATTERNS

www.edimax.com

EA-IO7D V2

Indoor 7dBi Omni-direconal

Desktop Antenna

SPECIFICATIONS

Maximum performance, actual data rates, and coverage will vary depending on network condions and environmental factors. Pro t specicaons and design are subject to change without noce. duc

www.edimax.com

Produktspecifikationer

Varumärke:	Edimax
Kategori:	TV-antenn
Modell:	EA-IO7D V2
Höjd:	280 mm
Frekvensband:	2.4 - 2.5 GHz
Diameter:	13 mm
Impedans:	50 Ω
Antennanslutning:	RP-SMA
Produktens färg:	Svart
Effekt:	2 W
Antal per förpackning:	1 styck
Antenn ökningsnivå (max):	7 dBi
Kommunikationsstandarder:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Antenntyp:	Rundstrålande antenn
Vertikal strålningsbredd:	25 °
Horisontell strålningsbredd:	360 °
Polarisation:	Horisontell polarisering
