Sida 1/3
ET-912+ Series
100Base 10/100BaseTX To 100Base-FX
Media Converter
Best media conversion solutions for network connectivity
Edimax’s full series of Media Converter are designed to meet the needs for massive optical fiber network,
provide the whole Ethernet / Fast Ethernet network implementation.
Migrating between copper and ber-based Medium
ET-912+ series convert the signals between two dierent transmission medium, allowing user a simple and
cost-eective method to migrate between UTP cable and ber optic cable. It can transmit signals up to 2km
(multimode) and 30/40/60/80/100km (single-mode) in ber medium, allowing users to extend network.
Comply with IEEE Standards
ET-912+ series are fully compliant with IEEE 802.3 10Base-T and 802.3u 100Base-TX, 100Base-FX standards.
The device comes with one RJ-45 port to connect to a 10/100Base-TX device such as workstation or switch
and one ber connection to connect a 100Base-FX device.
Built in Switching ASIC
ET-912+ series have turned the function more like a 2 ports switch than a traditional converter. User can get all
switching benets such as frames checking and ltering.
Feature LED and Fiber link alarm
User could monitor the device through Feature LED. In addition, Fiber Link Alarm could allow user to monitor
and maintain their critical ber link more eectively.
Unique voltage supervisor
Built in voltage supervisor IC will automatically reset all chipsets in converter as power voltage drop below 2.9V,
this action can make sure ber port and TP port work normally when thunder storm or power unstable occuring
cause the power
electricity suddenly down in an instant time.
Plug-and-Play Installation
Simply to plug the TP and ber port to the device having the media convertibility.
Features
•Compliant with IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX/100BaseFX Standards
•One 10/100BaseTX Ethernet TP Port and One 100BaseFX Ethernet Fiber Port
•One 100BaseFX Fiber Port can support either Multi (SC/ST) or Single (SC, LC, MT-RJ) Mode
•TP Port can support Half/Full-Duplex, Auto-MDI/MDI-X and Auto-Negotiation
•Providing a slide switch for Full- and Half-Duplex selection on FX Port
•Multiple Fiber Connectors
•Providing 19” Converter Chassis for up to 16 slots with redundant power supply for optional expansion use
Model Opcal Fiber Descripon
ET-912MSC+
10/100 to 100FX Mul Mode 2KM-SC
ET-912MST+
10/100 to 100FX Mul Mode 2KM-ST
ET-912SSC3+
10/100 to 100FX Single Mode 30KM-SC
ET-912SSC4+
10/100 to 100FX Single Mode 40KM-SC
ET-912SSC6+
10/100 to 100FX Single Mode 60KM-SC
ET-912SSC8+
10/100 to 100FX Single Mode 80KM-SC
ET-912SSCA+
10/100 to 100FX Single Mode 100KM-SC
ET-912SW2A+
WDM 10/100 to 100 Single Mode 20KM-A
ET-912SW2B+
WDM 10/100 to 100 Single Mode 20KM-B
ET-912SW4A+
WDM 10/100 to 100 Single Mode 40KM-A
ET-912SW4B+
WDM 10/100 to 100 Single Mode 40KM-B
Order Information
Specication
Standards
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX/100BaseFX
Features
Number of Ports:
1 10/100BaseT with RJ-45 Connector
1 100BaseFX with Fiber Connector (Mul/Single
Mode, ST/SC, LC, MT-RJ Connector)
Data Transfer Rate
Ethernet: 10Mbps/Half-Duplex
20Mbps/Full-Duplex
Fast Ethernet: 100Mbps/Half-Duplex
200Mbps/Full-Duplex
Transmission Media
10BaseT Cat. 3, 4, 5 UTP/STP, up to
100BaseTX Cat. 5 UTP/STP, up to
100BaseFX:
50/125μm or 62.5/125μm Mul Mode ST/SC-Type
Fiber opc cable, up to
9/125μm or 10/125μm Single Mode Fiber opc
cable
LED Indicators
Per Port:
(TX): Link/Act, Speed, FDX/COL
(FX): Link/Act, FDX/COL
Per Unit: Power
Power Requirement
DC5V/2A
Power Consumpon
10 Was (Max)
Dimensions
102 x 74 x 22mm(L x W x H)
Weight
230 g
Operang Temperature
0 to 60℃
Storage Temperature
-20 to 90℃
Humidity
10 to 90% RH (non-condensing)
Cercaons
FCC Class B, CE
