Sida 1/3
ET-940MCR/950MCR
16 Slots Media Converter Chassis with Redundant Power Supply
Overview
The Edimax ET-940MCR/ET-950MCR media converter chassis providing more capacity to the converters in one
chassis, the ET-940MCR/ET-950MCR is able to host up to 16 Edimax’s ET-912+ and ET-913+V2 series media
converters.
All converters are individually secured into the chassis and can be hot-swapped for maximum connection
reliability. The Chassis is a standard 19 inch rack mountable size, to save more spaces for ber-optic wiring and
ease to maintain of media converters.
The dual hot-swappable power supplies ensure continues network operation, and independent power supply in
each bay of the ET-940MCR/ET-950MCR, you can freely install the converters without interrupting the rest of the
networks.
Key Features
•Supports up to 16 media converters
•Supports 19” standard rack-mount size
•Supports Fast Ethernet, Gigabit Ethernet, Single-mode and Multi-mode ber media converters
•Supports Hot-swappable of Media Converters and Power Supplies
•Two redundant power supplies with two cooling fans
Note: Supports for ET-950MCR. ET-940MCR can add extra power supply (ET-940PS) to support.
•Power isolation design to ensure each bay is electrically isolated from others
•Cost-eective and easy install
ET-940PS
Compatible Models
Model Optical Fiber Description
ET-912MSC+
10/100 to 100FX Multi Mode 2KM-SC
ET-912MST+
10/100 to 100FX Multi Mode 2KM-ST
ET-912SSC3+
10/100 to 100FX Single Mode 30KM-SC
ET-912SSC4+
10/100 to 100FX Single Mode 40KM-SC
ET-912SSC6+
10/100 to 100FX Single Mode 60KM-SC
ET-912SSC8+
10/100 to 100FX Single Mode 80KM-SC
ET-912SSCA+
10/100 to 100FX Single Mode 100KM-SC
ET-912SW2A+
WDM 10/100 to 100 Single Mode 20KM-A
ET-912SW2B+
WDM 10/100 to 100 Single Mode 20KM-B
ET-912SW4A+
WDM 10/100 to 100 Single Mode 40KM-A
ET-912SW4B+
WDM 10/100 to 100 Single Mode 40KM-B
Specication
Capacity
16 bays for up to 16 Media Converters
Power
ET-940MCR with AC Single Power Supply
ET-950MCR with AC Redundant Power Supply
ET- AC to DC Power Supply Module940PS
Input: 100 ~ 240V AC, 50 ~ 60Hz
Cooling
Two internal cooling fans
Dimensions
440 300 × × (L x W x H)
Operang Temperature
0 to 50℃
Storage Temperature
-20 to 70℃
Humidity
10 to 90% RH (non-condensing)
Cercaons
FCC Class A, CE
ET-940PS, Media Converter Chassis Power Supply
Dimensions
150 180 × × 90 mm(L x W x H)
Compatible Models
Model Optical Fiber Description
ET-913MSC+ V2
10/100/1000T to 1000SX Multi -Mode 550M SC
ET-913SSC1+ V2
10/100/1000T to 1000SX Single Mode 10KM-SC
ET-913SSC2+ V2
10/100/1000T to 1000SX Single Mode 20KM-SC
ET-913SSC3+ V2
10/100/1000T to 1000SX Single Mode 30KM-SC
ET-913SSC5+ V2
10/100/1000T to 1000SX Single Mode 50KM-SC
ET-913SSC6+ V2
10/100/1000T to 1000SX Single Mode 60KM-SC
ET-913SSC8+ V2
10/100/1000T to 1000SX Single Mode 80KM-SC
ET-913SW2A+ V2
WDM 10/100/1000 to 1000 Single Mode 20KM-A
ET-913SW2B+ V2
WDM 10/100/1000 to 1000 Single Mode 20KM-B
ET-913SW4A+ V2
WDM10/100/ 1000 to 1000 Single Mode 40KM-A
ET-913SW4B+ V2
WDM 10/100/1000 to 1000 Single Mode 40KM-B
ET-913SFP V2
10/100/1000T to 1000 SFP Media Converter
