USB 2.0 Slim HUB

Version 1.1

Contents

1 . 0 I n t r o d u c t i o n ………. . ……………………………. P. 2

2 . 0 Fea t u r e s ……………….…………………………. P. 2

3.0 Specification ………………………………………..P.3

4.0 Installation …………...…………….… … … … .…….P.3

- 1 -

USB 2.0 Slim HUB User's Manual

1.0 Introduction

This is designed in accordance to USB specification Rev 1.1/2.0 which act as a bridge

between the main computer host and the down stream USB devices. It is able to complement

PC serial interface by connecting a full range of peripherals, which is very simple and flexible

for the users.

There is one upstream port that connects to the PC host and there are four down steam ports

connecting up to 127 USB devices in a tiered-star configuration. It supports both full speed

(480M bps) and low speed (1.5M bps) devices which include keyboards, mice, scanner.

It is also protected by automatic per-port over-current detection and recovery and the LED

indicating the connection status and power source.

2.0 Features

z Full compliance with USB specification Rev. 1.1.

z With one up-stream port and four down-stream ports.

z Connects up to 127 devices in a tiered star configuration.

z Supports both full-speed (12M bps) and low-speed (1.5M bps) devices.

z Select between self-powered mode and bus-powered mode automatically.

z Per port over current detection/protection and power switch control.

z LED for bus-power, self-power and four down-stream connection status.

LED light

DC Jack

USB port

- 2 -

Produktspecifikationer

Varumärke:	Edimax
Kategori:	Gränssnittshubb
Modell:	EU-HB4S
Gränssnitt:	USB 2.0/1.1
Kompatibla operativsystem:	Windows 98Se, Me, 2000, XP, Vista, Linux
Faktisk dataöverföringshastighet:	480 Mbit/s
Mac-kompatibel:	Ja
Antal anslutningar:	4
Anslutna USB-enheter mängd (max):	4
