Sida 1/2

3Mpx PoE True Day & Night Box Network Camera

Overview

The Edimax NC-213E is an ONVIF compliant true day and night network camera with QXGA (2048 x 1536) video

resoluon at 20fps, which allow you to capture detailed videos in daylight or at night. With Edimax’s superior

H.264 video compression technology, the NC-213E can create high quality videos with small le sizes, allowing

for opmized network bandwidth eciency.

The - comes with EdiView32 soware - a 32-channel viewing, recording and management program NC 213E

that allows for simultaneous live monitoring and high-resoluon video recording. Addionally, with the

Edisecurity Smartphone Viewer applicaon users will be able to see images from the - from any NC 213E

Internet connecon, anywhere in the world.

The Edimax NC-213E is built to produce high quality 3 megapixel videos that capture every detail in a

monitored area. You can set the camera to record Full HD 1080p (1920 x 1080) videos at 30 frames per second,

or even QXGA (2048 x 1536) videos at 20 frames per second. It oers true day and night funconality to

capture clear videos 24 hours a day, and the built-in SD/SDHC card slot allows for local data storage in the case

of a network disconnecon.

The NC-213E complies with the IEEE 802.3af Power over Ethernet standard, which enables power and data

transmission over a single Ethernet cable and eliminates the hassle of needing to install an addional power

adapter.

FEATURES

• True day and night support

• 5 megapixel CMOS sensor

• QXGA resoluon at 20fps

• H.264, MPEG-4 & M-JPEG mul-stream output

• Simultaneous live monitoring and high resoluon recording

• IEEE 802.3af Power over Ethernet support

• SD/SDHC memory card slot for local storage

• Mul-area moon detection

• 2-way audio support

• 3GPP mobile surveillance support

• -485 communicaon support RS

• ONVIF compliant

NC- 213E

Megapixels

H.264 MPEG-4 M-JPEG

2-Way

Audio

32CH

Viewer

PoE

802.3af

ICR

Maximum performance, actual data rates, and coverage will vary depending network condions and environmental factors. Product specicaons and design subject change without noce. on are to

www.edimax.com

3Mpx PoE True Day & Night Box Network Camera

NC- 213E

SPECIFICATIONS

IP SURVEILLANCE APPLICATIONS

Image Sensor

Type

1/2.5" CMOS

Lens

Focal Length / F-Number

C Mount Fixed Lens, f = 6.0mm, F1.4

DC- Iris

DC-Iris Support

Day Night Operaon / IR Distance

Mechanical ICR

Min. Illuminaon

1 Lux at F1.2

Video Compression

H.264 MPEG-4 / M-JPEG /

Max Resoluon

QXGA (2048 x1536) @ 20FPS

Special Features

Event Trigger

Moon Detecon, Alarm, Schedule

Digital In / Out Points

2 In / 1 Out

Digital Zoom

10x

RS-485 Support

Yes

Smartphone Monitoring

Free iPhone, Android App

WDR Support

Storage

1 SD/SDHC Card Slot, up to 32GB

Audio Interface

1 Built- Microphone / 1 In / 1 Out In

Network

10BASE-T / 100BASE- TX

Power Supply

DC 12V / AC 24V / (IEEE 802.3af) PoE

Operang Temperature

C - 50

Dimensions (mm)

131(D) x 72.2(W) x 206.7(H)

Weight (g)

390

Weather-proof

Vandal-proof

Cercaon (EMI, IP, RoHS)

CE / FCC / RoHS

ONVIF Support

v 1.02

www.edimax.com

hp://security.edimax.com

Maximum performance, actual data rates, and coverage will vary depending network condions and environmental factors. Product specicaons and design subject change without noce. on are to

www.edimax.com

Produktspecifikationer

Varumärke:	Edimax
Kategori:	ej kategoriserat
Modell:	NC-213E
Bredd:	72 mm
Djup:	130 mm
Höjd:	58 mm
Wi-Fi:	Nej
Videoformat som stöds:	H.264, M-JPEG, MPEG4
Videolägen som stöds:	1080p, 720p, 960p
Maximal upplösning:	2048 x 1536 pixlar
Inbyggd hårddisk:	Nej
Certifiering:	CE, FCC
Optisk sensorstorlek:	1/2.5 "
Bildsensortyp:	CMOS
Digital zoom:	10 x
Optisk zoom:	- x
Grafikupplösningar som stöds:	176 x 144,320 x 240,720 x 480,1280 x 960,1280 x 720 (HD 720),1920 x 1080 (HD 1080),2048 x 1536 (QXGA),640 x 480 (VGA)
Modell:	IP-säkerhetskamera
RS-485-portar:	1
Typ av minneskort:	SD, SDHC
Produktens färg:	Svart
Inbyggd kortläsare:	Ja
Formfaktor:	Låda
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 50 ° C
Hållbarhetscertifiering:	RoHS
Placeringar som kan användas:	Utomhus
Anslutningsteknologi:	Kabel
Minimibelysning:	1 lx
Mörkerseende:	Ja
Bildfrekvens:	30 fps
Nätverksansluten (Ethernet):	Ja
Stöd för nätverksprotokoll:	TCP/IP, IPv6, IPv4, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, HTTPs, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP
Filtrering för IP-adress:	Ja
Strömkälla av typen:	PoE
Efterlever industristandard:	IEEE802.3af
Larm ingång / utgång:	Ja
