REMOTE CHASER
Caution! Always disconnect from main power before servicing. There may be high voltage run-
ning through console. Remember to always replace with same type fuses.
For service, contact Elation Professional®.
© Elation Professional® Los Angeles, CA 90058 USA • Visage Remote Chaser Instruction Page 1
User Instructions
VISAGE
Technical Specifications:
Model - VISAGE
Dimensions: 7.75” x 6.5” x 2.75”
Weight:
4 lbs.
Output load: 5A per channel or 15 MAX.A
(600W per channel)
Power: 120V 50-60Hz
1
2
3
4
5
6
7
8
9
10
Thank you for purchasing the VISAGE by Elation®. For your convenience this product has been tested
and is ready to be used. There is no assembly required. Please read the following instructions before
installing or using your new unit.
The VISAGE Remote Chaser features 16 built-in chasing patterns with Auido/Chase modes and Four AC-120V, 3-prong
UL sockets for channel output. In AUDIO mode, the patterns are executed with the music rhythms detected by the inter
-
nal microphone. In CHASE mode, the chasing speed can be adjusted. A wireless remote controller is provided for full
control capabilities.
Product Description
1. POWER OUTPUT: Four 3-prong UL socket, 5A/CH.,
15A MAX.
2. SPEED UP BUTTON: Press to increase the chasing
speed.
3. SPEED DOWN BUTTON: Press to decrease the
chasing speed.
4. PATTERN UP SELECT: Select desired chasing pattern
by pressing to increase by one.
5. PATTERN DOWN SELECT: Select desired chasing
pattern by pressing to decrease by one.
6. AUDIO/CHASE SELECT & INDICATOR: Press to
select chasing mode from AUDIO/CHASE.
7. FULL ON BUTTON: Press to make all channels at full
intensity.
8. STAND BY: Press to pause all channels.
9. BUILT-IN MICROPHONE: Used to detect AUDIO signal.
10. CHANNEL INDICATOR: Lights when appropriate
channel is turned on.
General Functions (Front)
© Elation Professional® Los Angeles, CA 90058 USA • Visage Remote Chaser Instruction Page 2
1. Press to increase or Speed / Buttons:
decrease the chasing patterns’ speed.
2. Press to engage chaseAudio/Chase Button:
to sound mode. The red LED will indicated sound
active mode.
3. This functions as a ‘Blackout’Stand By Button:
feature (All channel turn off
). A yellow LED will
indicate Stand By mode.
4. This will activate full on Full On Button:
mode ( ).All channels on full
5. Press to select Pattern / Buttons:
one (1) of 16 built in programs.
BATTERY WARNING!: Remove the batteries when the
remote will not be in use for a long period of time. Never mix
old and new batteries or batteries of different type. Always
load the batteries with the correct polarity.
CAUTION!: Direct sun light may impede the infrared operation of the remote.
11. POWER SWITCH: Press to turn the power ON or OFF.
12. CHANNEL FUSE: 6. 3A 250V
13. POWER INPUT: AC 120V - 50/60Hz
14. INFARED SENSOR
15. INFARED RECEIVING SENSOR SOCKET: Plug in
remote infared detector for remote control.
16. LINK IN: This will receive data from another units
‘LINK OUT’.
17. LINK OUT:
This will send data to another unit.
FUSES: F6.3A 250V 5x20mm
1 2 3 4
POWER INPUT
POWER
AC 120V~50-60Hz, 15A
LIN
K
EXT.
REMOTE
INFRARED
SENSOR
IN
OUT
WARNING:
TH IS A PPAR AT US MUS T BE E AR THED .
N'OUVREZ PAS..RISQUE DE CHOCELECTRIQUE
RISK OF ELECTRIC SHOCK,
DO NOT OPEN.
CAUTION:
23-020-0071
MADE IN CHINA
OUTPUT: 5A/CH, TOTAL 15A Max.
11
12 13
14 15 16 17
General Functions (Rear)
Remote Controller Controls & Functions
1. Connect lamps or groups of lamps to any or all the UL 3-prong sockets on the unit. Each outlet can
handle a maximum of 5 amps. The pack can handle 15 amps maximum.
2. Turn the units’ power on.
3. Adjust the chase speed by selecting the andSPEED .
4. Select your chase pattern by selecting the PATTERN
and .
5. All adjustments can also be made by the remote control.
6. To chase to sound, press the AUDIO/CHASE BUTTON.
7. When mounting this chaser in an area that may obstruct the remote controls infrared path an optional
external remote infrared detector can be used and mounted in an area that will give the user a clean
shot from the remote control.
Operating Instructions
Technical Specifications:
Model - Visage Remote
Voltage: 2 AA 1.5v Alkaline Battery
Fuse: None
Dimensions: 5” x 1.75” x .75”
Weight: 1 lbs.
Range: Approx. 30ft.
