Sida 1/20
I O Mnstallation and peration anual
EVID
™
Ceiling
Speaker
Systems
ii EVID™ Ceiling Series Installation and Operation Manual
Table of Contents. . . . . . . . . . . . . . . . . . . . . . . ii
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Important Features . . . . . . . . . . . . . . . . . . . . . 1
Model Summary. . . . . . . . . . . . . . . . . . . . . . . . 2
Packing List . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Feature Identification. . . . . . . . . . . . . 3
Installation and Wiring. . . . . . . . . . . . . . . . . . . 4
Step 1 — Cut the Hole . . . . . . . . . . . . . . . . 5
Step 2 — Install C-Ring
and/or Tile Rails . . . . . . . . . . . . . . . . . . . 5
Step 3 — Attach Wiring to the
Terminal Connector . . . . . . . . . . . . . . . . 5
Step 4 — Secure the Cable to the
Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 5 — Mount the Speaker into the
Ceiling . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 6 — Connect an Auxiliary
Support Line . . . . . . . . . . . . . . . . . . . . . . 8
Step 7 — Adjust Tap Selector . . . . . . . . . . . 8
Step 8 — Insert the Grille . . . . . . . . . . . . . . 8
Appendix A — Painting the Speaker . . . . . . . . 9
Appendix B — System Design Guide . . . . . . 10
Selecting and Positioning Ceiling
Loudspeakers . . . . . . . . . . . . . . . . . . . . 10
Ceiling Systems: Size vs. Coverage. . . . . . . 10
Use of Subwoofers . . . . . . . . . . . . . . . . . . 11
Appendix C — Troubleshooting Table. . . . . . 12
Appendix D — Warranty . . . . . . . . . . . . . . . . 13
Exclusions and Limitations . . . . . . . . . . . . 13
Appendix E — Product Specifications . . . . . 14
Table of Contents
Welcome
Thank you for purchasing EVID™ Ceiling Series
loudspeakers. Read through this manual to
familiarize yourself with features, applications,
and precautions before you use these products.
EVID Ceiling Series loudspeakers use innova-
tive design and materials to provide premium-
level performance in a flush-mount ceiling for-
mat. Four models comprise the EVID Ceiling
Series: the C4.2 with a 4-inch LF driver and a
.75-inch, titanium-coated tweeter with wave-
guide; the C8.2 with an 8-inch LF driver and a
1-inch titanium-coated tweeter with waveguide;
the C8.2HC with a fully waveguide-loaded 8-
inch LF driver and a 1-inch titanium coated
tweeter; and the EVID 10.1, a true ceiling-mount-
ed subwoofer designed to augment and extend
the full-range model’s low-frequency response.
Important Features
• Matches acoustically to the EVID surface-
mount speaker line
• Model for model, has superior performance
to competing brands
• Comes with both 70V/100V or 8-ohm opera-
tion standard on every model
• Includes all installation accessories
commonly needed for most jobs
1EVID™ Ceiling Series Installation and Operation Manual
Welcome/Important Features
ATTENTION: UL SAFETY LISTING
All EVID ceiling speaker models are list-
ed under UL standar UL1480 as a signalingd
speaker. C8.2LP,The EVID models C8.2,
C8.2HC and C10.1 models are also suitable for
use in air handling spaces per UL2043.
The EVID C4.2 is not UL listed for use in air
handling spaces.
!
