EVID FM6.2
Dual 6.5” Two-Way
Flush-Mounted
Loudspeaker System
Key Features:
• 6.5”two-waysystemwithpolypropylenediaphragmforreli-
ablelong-termoperation.
• 6.5”passiveradiatorcoupledtothewooferdramatically
extendsandsmoothesthelowfrequencyresponse.
• Extremelycompactdepthfitsintotightspacesincluding
wallsandtightceilingspaces.
• Titaniumcoatedtweetergivesevenuniformhighfrequency
coverage
• Fullbandwidthoverloadprotection
• Frontbafflewattagetapadjustmentallowsforeasylevel
matchingafterinstallation.
• Easy4pinphoenixstyleterminalsforquickinstallation
• Integratedlowlossmatchingtransformerallowsforeither
70v/100vor8ohmoperation.
General Description:
TheElectro-Voice®EVIDFM6.2loudspeakersystemisacomplete
two-wayin-wallloudspeakerpackage.Thepackageconsistsofabezel
assembly,grille,rearenclosure,6.5”two-wayloudspeakercoupledwith
a6.5”passiveradiatorandaninternalline-matchingtransformer.The
loudspeakerfeatures6.5”low-frequencyconeandhigh-temperature
voice-coilassemblyalongwitha6.5”longexcursionpassiveradiator
andtitaniumcoateddometweeter.TheEVIDFM6.2loudspeakeruti-
lizesacrossovernetwork,centeredat3,300Hz,thatprovides16-dB-
per-octavetweeterprotectionoutsideofitsoperatingrange.Inaddition
theFM6.2featuresacomprehensiveprotectioncircuittoshieldthe
wooferandtweeterdriversfromexcessivepowerlevels.
TheFM6.2utilizesatransformerthatoffersaselectionof7.5,15,30,
or60wattsdeliveredtotheloudspeakersystemusingeither70-Vor
100-Vlines.Thewattageisselectedviaaconvenientswitchonthe
frontbaffle.Theunitcanalsobeoperatedasan8-ohmspeakerviathe
samefrontpanelselectorswitch.
Theperforatedgrilleisfinishedinsemi-glosswhitepowder-coated
enamel.ThebaffleandbezelisconstructedfromheatresistantABS.
Therearenclosureisconstructedfromzinc-plated,steel.Therear
enclosureprovidesanoptimuminternalvolume,ensuringextendedlow-
frequencyperformance.Itisconstructedfromheavy-gauge,rugged
steel.ThesteelrearenclosurewasoptimizedusingFEAtovirtually
eliminatepanelresonance.Theentireenclosureislessthan4”deep
providinganeasyinstallationintonearlyanytightwallorceilingspace.
Arearcover,withprovisionsforajunctionboxfitting,providesaccess
toa4-pinterminalblockthatallowsdirectconnectiontothespeaker
andprovidespassthroughtoadditionalspeakers.FM6.2loudspeakers
providewidedispersion,high-efficiency,high-maximumoutput,easeof
installation,andwide-rangereproductionofmusicorvoice.
Technical Specifications:
Freq.Response(-3dB): 60Hz-20kHz
Freq.Range(-10dB): 52Hz-20kHz
AxialSensitivity: 90dB(SPL1W/1m)
Impedance: 8ohmsnominal(transformerbypass)
CrossoverFrequency: 3.3kHz
Rec.HighpassFrequency: 60Hz
PowerHandling1: 150WCont.Prog./300WPeak
HFTransducer: 1in.(25.4mm)
LFTransducer:
PassiveRadiator:
6.5in.(165.1mm)
6.5in.(165.1mm)
TransformerTaps: 70V:7.5,15,30,or60W
100V:15,30,or60W
Bypass:8ohmsnominal
Connectors: 4pinphoenixstyleterminals
EnclosureMaterial: Baffle:UL94V-OratedABS
Backcan:Zincplatedsteel
Grille: Perforatedpowdercoatedsteelwithsafety
tether
MountingSystem: Integratedtoggleanchors
SupportHardware: Cutouttemplate,Paintshield
Dimensions: 465.4mmx256.4mmx100.3mm
(18.32”x10.09”x3.95”)
NetWeight(Each): 5.8kg(12.7lb)
ShippingWeight(Pair): 12.9kg(28.4lb)
AllSpecificationsbasedonHalf-SpaceEnvironmentasflush-mounted.
1ContinuousProgramRating:3dBgreaterthancontinuouspinknoise
rating(IEC-shapedpinknoisewith6dBcrestfactor)
Architects’ and Engineers’
Specifications:
TheEVIDFM6.2loudspeakersystemshallbecomprisedofabaffle/bezel
assembly,frontgrille,rearenclosure,transformer,6.5”passiveradiator,
and6.5”loudspeaker.Theloudspeakerwillfeaturean6.5”low-frequency
coneandahigh-temperaturevoice-coilassembly,coupledwitha6.5”
passiveradiator.A1”widedispersiontitaniumcoateddometweeter
extendstheresponseto20kHz.Frequencyresponse,uniformfrom85Hz
to18kHz.Pressuresensitivity,90dBSPLat1meter(88dBat4feet)on
axiswithonewattofband-limitedpinknoisefrom500Hzto3kHz(ref.
20µPa).Minimumimpedance,8.6ohms.Theloudspeakershallbe465.4
mm(18.32in.)by256.4mm(10.09in.and100.3mm(3.95in.)deep.
Weightshallbe5.8kg.(12.7lb)Thein-wallloudspeakerspackagesshall
betheElectro-Voice®modelFM6.2.
12000PortlandAvenueSouth,Burnsville,MN55337
Phone:952/884-4051,Fax:952/884-0043
www.electrovoice.com
©BoschCommunicationsSystems 07/2009
Part Number LIT000235 Rev 3
U.S.A.andCanadaonly.Forcustomerorders,contactCustomerServiceat:
800/392-3497 Fax: 800/955-6831
Europe,Africa,andMiddleEastonly.Forcustomerorders,contactCustomerServiceat:
+ 49 9421-706 0 Fax: + 49 9421-706 265
OtherInternatonallocations.Forcustomerorders,ContactCustomerServiceat:
+ 1 952 884-4051 Fax: + 1 952 887-9212
Forwarrantyrepairorserviceinformation,contacttheServiceRepairdepartmentat:
800/685-2606
Fortechnicalassistance,contactTechnicalSupportat:866/78AUDIO
Specificationssubjecttochangewithoutnotice.
Frequency Response:
Beamwidth:
Directivity:
Block Diagram:
Dimension Drawings:
Performance Match:
• D170406 PA2400T,2x40070vPowerAmplifier
• D170407 PA2250T,2x25070vPowerAmplifier
• D170408 PA2450L,2x450PowerAmplifier
• D170409 PA4150L,4x150PowerAmplifier
EVID FM6.2 Part Numbers:
• PRD000121-000
20
50
100
1000
10000
20000
3.16
10
100
316
70
80
90
100
110
Sensitivity (dB)
Impedance (Ohms)
Frequency Response, Half Space
Impedance
Electro-Voice®
Horizontal Vertical
Beamwidth (First Crossing)
Frequency (Hz)
-6dB Beamwidth (degrees)
50
100
360
20
3.6
20 100 1000 10000 20000
20
100
1000
10000
20000
0
10
20
30
1
10
100
1000
Frequency (Hz)
Directivity Index (DI), dB
Directivity Factor (Q)
