HA-3

Handle Mount Kit

for Zx3 Series

Installation Instructions

HA-3 Handle Mounting Kit

The Electro-Voice HA-3 Handle Mounting Kit features a threaded attach point that allows for a Zx3 loudspeaker to

be ﬂown using a VSA-1 Strong-Arm (sold separately) to obtain desired orientation and sound coverage.

12000 Portland Avenue South, Burnsville, MN 55337

Phone: 952/884-4051, Fax: 952/884-0043

www.electrovoice.com

Part Number LIT000160 Rev B

U.S.A. and Canada only. For customer orders, contact Customer Service at:

800/392-3497 Fax: 800/955-6831

Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:

+ 49 9421-706 0 Fax: + 49 9421-706 265

Other Internatonal locations. For customer orders, Contact Customer Service at:

+ 1 952 884-4051 Fax: + 1 952 887-9212

For warranty repair or service information, contact the Service Repair department at:

800/685-2606

For technical assistance, contact Technical Support at: 866/78AUDIO

Speciﬁcations subject to change without notice.

Electro-Voice

WARNING: Suspending any object is potentially

dangerous and should only be attempted by in-

dividuals who have a thorough knowledge of the

techniques and regulations of rigging objects

overhead. Electro-Voice strongly recommends

that Zx3 speakers be suspended taking into account all

current national, federal, state and local regulations. It is the

responsibility of the installer to ensure that Zx3 speakers

are safely installed in accordance with all such regulations.

If Zx3 speakers are suspended, Electro-Voice strongly rec-

ommends that the system be inspected at least once a year.

If any sign of weakness or damage is detected, remedial

action should be taken immediately.

Step 1: Remove Handle Bolts and Handle

Fully Assembled with HA-3

Handle Mount and VSA-1

Strong-Arm Mount

Step 2: Attach HA-3 and Handle Bolts Step 3: Attach VSA-1 Strong-Arm Mount

HA-3

Handle Mount

VSA-1

Strong-Arm

TCA-1

Truss Clamp

Adaptor
