Sida 1/82

1. Introduction ........................................................................................................................................................................................... 6

1.1 Preface ...................................................................................................................................................................................................................................6

1.2 Packing List ..........................................................................................................................................................................................................................6

1.3 Caution ..................................................................................................................................................................................................................................7

1.4 Connection ..........................................................................................................................................................................................................................8

1.5 First Time Usage ............................................................................................................................................................................................................. 11

2. About the Player ................................................................................................................................................................................11

2.1 Remote Control ............................................................................................................................................................................................................... 11

2.2 Front Panel ....................................................................................................................................................................................................................... 13

2.3 Rear Panel ....................................................................................................................................................................................................................... 13

2.4 Side Panel ....................................................................................................................................................................................................................... 13

3. Getting Started ...................................................................................................................................................................................14

3.1 * Selecting DVB-T TV (For Q800 only) .................................................................................................................................................................. 14

3.2 * Selecting Analog TV (For Q800 only) .................................................................................................................................................................... 14

3.3 Selecting A/V In – Signal from the A/V IN jack ..................................................................................................................................................... 14

3.4 Selecting Playback – Playback and Edit Recorded Titles .................................................................................................................................. 14

3.5 Selecting Browser – Playback Multimedia Files ................................................................................................................................................... 14

3.6 Selecting Internet Radio .............................................................................................................................................................................................. 15

4. * Watching Analog & DVB-T TV programs (For Q800 only) .................................................................................................15

4.1 * Watching Analog TV programs (For Q800 only) ............................................................................................................................................... 15

4.2 * Watching DVB-T TV programs (For Q800 only) ................................................................................................................................................. 15

5. The Title List Menu for Recorded Videos ....................................................................................................................................17

5.1 Title List Menu .................................................................................................................................................................................................................. 17

5.2 Playing Back Titles .......................................................................................................................................................................................................... 17

5.3 Deleting Titles .................................................................................................................................................................................................................. 17

5.4 Renaming Titles ............................................................................................................................................................................................................... 18

5.5 Sorting Files ...................................................................................................................................................................................................................... 18

5.6 Title Edit Menu ................................................................................................................................................................................................................. 18

5.7 Tools ..................................................................................................................................................................................................................................... 20

5.8 Saving Your Recorded Titles ....................................................................................................................................................................................... 20

6. Timer Record Menu ...........................................................................................................................................................................20

6.1 Create a New Schedule ................................................................................................................................................................................................. 20

6.2 Editing Schedule ............................................................................................................................................................................................................. 21

6.3 Deleting Schedules ........................................................................................................................................................................................................ 21

6.4 Viewing Schedule Status ............................................................................................................................................................................................. 21

6.5 Viewing Recording History .......................................................................................................................................................................................... 21

7. Setup Menu ..........................................................................................................................................................................................22

7.1 * Changing DVB-T TV settings (For Q800 only) .................................................................................................................................................... 22

7.2 * Changing Analog TV settings (For Q800 only) .................................................................................................................................................. 23

7.3 Changing Video Settings ............................................................................................................................................................................................. 24

7.4 Changing Audio Settings ............................................................................................................................................................................................. 25

7.5 Changing Record Settings ........................................................................................................................................................................................... 25

7.6 Changing Network Settings ....................................................................................................................................................................................... 27

7.7 Changing System Settings .......................................................................................................................................................................................... 27

7.8 Miscellaneous .................................................................................................................................................................................................................. 30

8. Browser Menu......................................................................................................................................................................................31

8.1 Browsing All ...................................................................................................................................................................................................................... 31

8.2 Browsing Music ............................................................................................................................................................................................................... 31

8.3 Browsing Photos ............................................................................................................................................................................................................. 31

8.4 Browsing Movies ............................................................................................................................................................................................................. 31

8.5 Browsing via Network ................................................................................................................................................................................................... 31

8.6 Renaming / Deleting Files ........................................................................................................................................................................................... 33

8.7 Managing the Playlist ................................................................................................................................................................................................... 33

9. File Copy Menu ...................................................................................................................................................................................34

10. NAS function .....................................................................................................................................................................................35

11. Listening to Internet Radio...........................................................................................................................................................36

11.1 Station List Menu ......................................................................................................................................................................................................... 36

11.2 Genre List Menu............................................................................................................................................................................................................ 36

11.3 My Favorite Station ...................................................................................................................................................................................................... 36

12. Upgrading the Firmware ...............................................................................................................................................................37

13. Appendixes ........................................................................................................................................................................................38

13.1 Specications ................................................................................................................................................................................................................. 38

13.2 Frequently Asked Questions .................................................................................................................................................................................... 39

13.3 Copyrights and Trademarks ..................................................................................................................................................................................... 41

13.4 Warranty .......................................................................................................................................................................................................................... 41

13.5 Licence Information .................................................................................................................................................................................................... 41

Content

1. Introduction

1.1 Preface

Dear Customer,

Thank you very much for purchasing the Movie Cube Q700/800. In the digital era, this product is a great home entertainment

partner. With the outstanding design, you can enjoy movies and music, view photos of precious moments, and record your

favorite TV or movie programs and view them in your own time. The editing function provides you with an easy way to back up

your data. Thanks to its built-in HDD and high-speed UBS 2.0, it’s easy to use Movie Cube Q700/800 as a portable external storage

device.

This player has the following functionalities:

Video Recording - Integrates both functions of direct recording and scheduled recording;

Allows easy recording of programs from DVB-T / Analog TV, DVD player, DV etc. and saving as

MPEG-2 (.mpg, or .ts) format;

Allows also editing the recorded titles;

Time shifting - Allows recording and watching a broadcast at a more convenient time;

Movie Playback - Supports VOB (DVD), IFO (DVD), MPG (MPEG-2/1), AVI (MPEG-4 ASP: XviD), DAT (VCD),

and MPEG-2 TS les; resolution up to 1080i;

Music Playback - Supports MP3, OGG, and WMA les*;

- Simple-to-use thanks to a unique button for playlist / music playback;

Photo Playback - Supports digital camera JPEG, and BMP les;

Data Storage - Works as a portable hard disk using USB 2.0 port;

Network Function - Ethernet & WLAN streaming playback and NAS functions (Wireless function is available with the

optional Wireless LAN USB Adapter);

HDMI - High-Denition Multimedia Interface transmits the highest quality digital video and audio via a

single cable, simplies cabling and provides high quality home theater experience;

* Analog TV - Supports analog PAL B/G, D/K, I, SECAM L and L’ reception;

* DVB-T TV - Supports Digital Video Broadcasting Terrestrial (DVB-T) TV reception;

- Supports Electronic Program Guide (EPG) and Teletext.

We hope that this product will bring you a lot of enjoyment. We are committed to apply multimedia technology in your work,

entertainment, family, daily life, car and everywhere! Welcome to EMTEC. Thank you again for choosing our Movie Cube Q700/800.

*Note: WMA Pro & Advanced Prole and WMA with DRM are not supported

You can nd forums on the Internet where users responding to most of your questions on all models of Movie Cube such

as www.mhdworld.com

1.2 Packing List

Part Quantity

Player 1

A/V cable 1

SCART in adapter 1 (no need for USA)

USB cable 1

Remote Control 1

Remote Control Battery 2

AC/DC adaptor 1

AC/DC adaptor Power Cord 1

English User Manual (printed) 1

Quick Installation Guide 1

Warranty card 1

Driver CD (with User Manual) 1

Wireless LAN USB Adapter 1 (optional)

* DVB-T Antenna 1 (optional)

Note: The actual contents in the package might be dierent from the packing list in this manual.

1.3 Caution

This player’s design and manufacture has your safety in mind. In order to safely and eectively use this player, please read

the following before usage.

1.3.1 Usage cautions

User should not modify this player. If commercial hard disk is being used, the environmental temperature should be within

+5°C ~ +35°C.

1.3.2 Power

The player’s power voltage: DC 12V. When using this player, please connect the supplied AC adapter or AC adapter cable to the

player’s power jack. When placing the adapter cable, make sure it can not get damaged or be subject to pressure. To reduce the

risk of electric shock, unplug the adapter rst before cleaning it. Never connect the adapter to the player in a humid or dusty area.

Do not replace the adapter or cable’s wire or connector.

1.3.3 Radio interference/compatibility

- If not properly shielded, almost all electronic devices will get radio interference. Under some conditions, your player might get

interference.

- The design of this player has followed the FCC/CE standard, and has followed the following rules:

(1) This player may not cause harmful interference;

(2) This player could accept some interference, including interference that may cause undesired operation.

1.3.4 Repair

If the player has a problem, you should take it to an appointed repair center and let the specialists do the repair, never repair the

player yourself, you might damage the player or endanger yourself or your data.

1.3.5 Disposing of the player

When you dispose of the player, be sure to dispose it appropriately. Some countries may regulate disposal of electrical device,

please consult with your local authority.

1.3.6 Hard disk cautions

The player uses an internal hard disk for data storage, in normal case, formatting or repair is not required.

You should carefully read the < Frequently Asked Questions > chapter, and check our website for latest information before

formatting the hard disk.

- Physical impact may create bad sector in the hard disk, you can use CHKDSK to x the problem.

- All data stored in the player may be lost due to physical impact, electrical shock, power lost, HDD format etc. Please backup your

data.

- It is suggested to do defragment after a long period of usage.

- Regularly backup the data in the hard disk so that it can be recovered in the event of data corruption or loss. Our company takes

no responsibility for loss of data stored on the hard disk.

1.3.7 Others

When using this player, please do not let the player come into contact with water or other liquid, if water is accidentally spilled on

the player, please use a dry cloth to absorb the spillage.

Electronic products are vulnerable, when using please avoid shaking or hitting the player, and do not press the buttons too hard.

Do not let the player come into contact with water or other liquid.

Do not disassemble the player, repair the player or change the design of the player, any damage done will not be included

in the repair policy.

Do not press the buttons of the player too hard.

Avoid hitting the player with hard object, avoid shaking the player, and keep it away from magnetic elds.

During electrostatic discharge and strong electromagnetic eld, the product will malfunction, then unplug the power

cable so that the product will return to normal performance next time it is powered on.

•

Produktspecifikationer

Varumärke:	Emtec
Kategori:	Extern hårddisk
Modell:	Movie Cube Q800
Vikt:	1530 g
Bredd:	212 mm
Djup:	152 mm
Höjd:	57 mm
Förpackningens vikt:	2.8 kg
Förpackningens bredd:	155 mm
Wi-Fi:	Nej
Ljudformat som stöds:	MP3, OGG, WMA
Videoformat som stöds:	AVI, DAT, IFO, MPG, VOB
Snabbstartsguide:	Ja
Modell:	HDD
Kompatibla operativsystem:	Windows 98SE, ME, 2000, XP, Vista, Mac OS X
Produktens färg:	Svart
Ytterförpackningens längd:	520 mm
Produkter per lastpall:	112 styck
Lastpallens bruttovikt:	360000 g
Ytterförpackningens bredd:	335 mm
Nätverksegenskaper:	10/100Mbps Ethernet
Hårddiskkapacitet:	500 GB
Nätverksansluten (Ethernet):	Ja
Bildkomprimeringsformat:	BMP
Antal USB 2.0 anslutningar:	3
Manual:	Ja
Intern:	Nej
Mac-kompatibel:	Ja
Externa anslutningar:	1xCVBS A/V, \n1x Y/Pb/Pr, \n1xHDMI V1.1, \n1xSPDIF, \n1xTV in.
Paketlängd:	250 mm
USB kabel:	USB
Pallet-mått (B x L x H):	800 x 1200 x 1480 mm
Bruttovikt på ytterkartongen:	11.9 kg
