Sida 1/4

Datasheet

over-Ethernet (PoE) adapter soluon is ideal

for installers to deploy PoE devices scalable,

and to reduce maintenance cost and labor

fee.

The ideal soluon could assist installers to solve the limitaon

in designing networks is the availability of power source. The

EnGenius PoE adapter allows delivery of both data and power

to compable Access Points or device over a single Ethernet

cable, allowing deployment of them exactly when users

needed to provide the best wireless coverage and at much

lower installaon cost.

Besides built-in networking facility, EPA series is also equipped

with short-circuit and overload protecon to assure the

securable and reliable connecon for Access Points or other

PoE devices. By sending direct current (DC) output, Ethernet

terminals which need more power such as wireless LAN high

power device, IP media center, and web camera are powered

remotely.

Features

> Scalable deployment by powering devices

from up to 100 meter (328 feet) remote-end

> Signicantly reduce maintenance cost and

labor fee

Physical Interfaces

LED INDICATORS

AC Connector

POE

LAN

Reset

(For GR models only)

Technical Specicaons Single Port Power-over-Ethernet (PoE) Adapter

Model EPA2406FP EPA2406GP EPA2406GR EPA2410GP

Power Specicaon

Input Voltage 100V~240V AC

Input Current 0.4A @ 120V AC 0.4A @ 120V AC 0.4A @ 120V AC 0.7A @ 120V AC

AC Input Frequency 50-60Hz

Max. Output Power 14.4W 14.4W 14.4W 24W

Power Line Pin4(Vdc+)&Pin5(Vdc+); Pin7(Vdc-)&Pin8(Vdc-)

Data Specicaons

Ethernet Ports Std. 10/100 Mbit/s 10/100/1000 Mbit/s

Data Lines Pin1(Rx+)&Pin2(Rx-); Pin3(Tx+)&Pin6(Tx-)

Protecon Level

Surge Protecon L-L: 2KV; L-G: 4KV L-L: 1KV; L-G: 2KV

ESD Contact 4KV; Air: 8KV

Other Protecon Over-voltage and over-current protecon; Short-circuit protecon

Physical Interfaces & Indicators

Ethernet Ports 1 x 10/100/1000 Data input; 1 x 10/100/1000 Data & power output

AC Connector 1 x IEC 320C6 AC connector (US, EU, UK, AU)

LED Indicator Power on : Green

Mechanical & Environment

Dimension 100mm x 58.4 mm x 33.4 mm (3.9” x 2.27” x 1.3”)

Weight (Adapter On-

ly)

112g (3.95oz) 112g (3.95oz) 112g (3.95oz) 144g (5.08 oz)

Temperatures Storage : -20 ~ 70°C (-4 ~ 158 °F ), Operaon : 0 ~ 40°C (42 ~ 140 °F )

Compliance Regulatory

CB IEC 60950-1: 2005+A1+A2

UL UL 60950-1 2

FCC FCC Subpart15 B

CE EN 55032:2012/AC:2013, EN 55024: 2010

RCM AS/NZS60950.1: 2011/Amdt 1: 2012

Warranty

1 year hardware warranty

Produktspecifikationer

Varumärke:	Engenius
Kategori:	nätverkskort/adapter
Modell:	EPA2410GP
LED-indikatorer:	Ja
Uteffekt:	24 W
Produktens färg:	Svart
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	2
Strömförsörjning via Ethernet:	120 V
Harmonized System (HS)-kod:	85044090
