Sida 1/4

Start Here

Load paper

See the online User’s Guide for instructions on loading paper in

the cassette 1 and rear paper slot, available paper types, sizes,

loading capacity, and loading CD/DVD/Blu-ray

™

discs (XP-630/

XP-830).

XP-630/XP-830

Output tray

Cassette 1 Cassette 2/front cover

You can load the following paper sizes:

• Cassette 1: 3.5 × 5-, 4 × 6-, or 5 × 7-inch photo paper

• Cassette 2: Letter-size, A4-, legal-size, or 8 × 10-inch paper

See the instructions below for loading paper.

• Rear paper feed slot: One sheet at a time (XP-830)

XP-530

Output tray

Cassette/front cover

You can load the following paper sizes: 3.5 × 5-, 5 × 7-, 8 × 10-

inch, letter-size, A4-, or legal-size.

1 Lower the front cover (if it’s not open already) and pull on

the front cover to pull out the paper cassette.

2 Slide the side edge guides outward and set the front edge

guide to the paper size you are using.

3 Insert the paper with the glossy or printable side

facedown.

Note: Make sure the paper is loaded against the front edge

guide and not sticking out from the end of the cassette.

Read these instructions before using your product.

The illustrations show the XP-830, but the steps are the same for

the XP-530 and XP-630.

Note for Spanish speakers/Nota para hispanohablantes:

Para obtener instrucciones de conﬁguración en español, consulte

la Guía de instalación en epson.com/support/xp530sp,

epson.com/support/xp630sp o epson.com/support/xp830sp

(requiere una conexión a Internet).

Unpack

(XP-630/XP-830)

Note:

• Do not open ink cartridge packages until you are ready to install the

ink. Cartridges are vacuum packed to maintain reliability.

• The CD/DVD tray is taped to the bottom of cassette 2.

1 Remove all protective materials from the product.

2 Lift up the scanner unit and remove all protective

materials.

3 Lower the scanner unit.

Turn on and configure

1 Connect the power cord to the back of the printer and to

an electrical outlet.

Caution: Do not connect to your computer yet.

2 Turn on the product, then adjust the control panel.

3 Select these settings:

XP-530/XP-630: Language

XP-830: Language, country, date, and time

Note:

• You can change these settings later using the product’s control

panel. For more information, see the online User’s Guide.

• If an error message appears, turn off the product and check

that no protective material has been left inside the product.

Install ink cartridges

1 Lift up the scanner unit.

Caution: Do not touch the ﬂat, white cable.

2 Gently shake the Black (BK) ink cartridge. Do not shake

Photo Black (PBK) or other ink cartridges.

3 Unpack the ink cartridges.

Caution: Do not touch the areas shown below. Doing so may

prevent normal operation and printing.

4 Remove the cap from each ink cartridge. Store the caps in

the included plastic bag.

Note: Save the caps and use them to recap the ink cartridges

after removing them for storage or disposal.

5 Insert the cartridges at an angle in the holder for each

color. Press each cartridge down until it clicks.

6 Lower the scanner unit.

7 The printer starts charging the ink. Ink charging takes

approximately 7 minutes. When you see a completion

message on the printer’s LCD screen, charging is

complete.

Caution: Don’t turn off the printer or raise the scanner unit while

the printer is charging or you’ll waste ink.

Note:

• The printer is designed for use with Epson

cartridges only, not

third-party cartridges or ink.

• The cartridges included with the printer are designed for

printer set up and not for resale. After some ink is used for

charging, the rest is available for printing.

XP-530/XP-630/XP-830 Small-in-One

Printer

Start Here

Load paper

See the online User’s Guide for instructions on loading paper in

the cassette 1 and rear paper slot, available paper types, sizes,

loading capacity, and loading CD/DVD/Blu-ray

™

discs (XP-630/

XP-830).

XP-630/XP-830

Output tray

Cassette 1 Cassette 2/front cover

You can load the following paper sizes:

• Cassette 1: 3.5 × 5-, 4 × 6-, or 5 × 7-inch photo paper

• Cassette 2: Letter-size, A4-, legal-size, or 8 × 10-inch paper

See the instructions below for loading paper.

• Rear paper feed slot: One sheet at a time (XP-830)

XP-530

Output tray

Cassette/front cover

You can load the following paper sizes: 3.5 × 5-, 5 × 7-, 8 × 10-

inch, letter-size, A4-, or legal-size.

1 Lower the front cover (if it’s not open already) and pull on

the front cover to pull out the paper cassette.

2 Slide the side edge guides outward and set the front edge

guide to the paper size you are using.

3 Insert the paper with the glossy or printable side

facedown.

Note: Make sure the paper is loaded against the front edge

guide and not sticking out from the end of the cassette.

Read these instructions before using your product.

The illustrations show the XP-830, but the steps are the same for

the XP-530 and XP-630.

Note for Spanish speakers/Nota para hispanohablantes:

Para obtener instrucciones de conﬁguración en español, consulte

la Guía de instalación en epson.com/support/xp530sp,

epson.com/support/xp630sp o epson.com/support/xp830sp

(requiere una conexión a Internet).

Unpack

(XP-630/XP-830)

Note:

• Do not open ink cartridge packages until you are ready to install the

ink. Cartridges are vacuum packed to maintain reliability.

• The CD/DVD tray is taped to the bottom of cassette 2.

1 Remove all protective materials from the product.

2 Lift up the scanner unit and remove all protective

materials.

3 Lower the scanner unit.

Turn on and configure

1 Connect the power cord to the back of the printer and to

an electrical outlet.

Caution: Do not connect to your computer yet.

2 Turn on the product, then adjust the control panel.

3 Select these settings:

XP-530/XP-630: Language

XP-830: Language, country, date, and time

Note:

• You can change these settings later using the product’s control

panel. For more information, see the online User’s Guide.

• If an error message appears, turn off the product and check

that no protective material has been left inside the product.

Install ink cartridges

1 Lift up the scanner unit.

Caution: Do not touch the ﬂat, white cable.

2 Gently shake the Black (BK) ink cartridge. Do not shake

Photo Black (PBK) or other ink cartridges.

3 Unpack the ink cartridges.

Caution: Do not touch the areas shown below. Doing so may

prevent normal operation and printing.

4 Remove the cap from each ink cartridge. Store the caps in

the included plastic bag.

Note: Save the caps and use them to recap the ink cartridges

after removing them for storage or disposal.

5 Insert the cartridges at an angle in the holder for each

color. Press each cartridge down until it clicks.

6 Lower the scanner unit.

7 The printer starts charging the ink. Ink charging takes

approximately 7 minutes. When you see a completion

message on the printer’s LCD screen, charging is

complete.

Caution: Don’t turn off the printer or raise the scanner unit while

the printer is charging or you’ll waste ink.

Note:

• The printer is designed for use with Epson

cartridges only, not

third-party cartridges or ink.

• The cartridges included with the printer are designed for

printer set up and not for resale. After some ink is used for

charging, the rest is available for printing.

XP-530/XP-630/XP-830 Small-in-One

Printer

Produktspecifikationer

Varumärke:	Epson
Kategori:	Skrivare
Modell:	Expression XP-830
Inbyggd display:	Ja
Vikt:	9752 g
Bredd:	391.2 mm
Djup:	337.8 mm
Höjd:	190.5 mm
Skärm diagonal:	4.3 "
Pekskärm:	Ja
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Maximal upplösning:	5760 x 1440 DPI
Internminne:	- MB
Kabelteknik:	10/100/1000Base-T(X)
Antal bläckpatroner:	5
Standardgränssnitt:	Ethernet, USB 2.0, Wireless LAN
Maximal kopieringsupplösning:	- DPI
Modemhastighet:	33.6 Kbit/s
Faxminne:	180 sidor
Fax:	Färgfaxning
Mobil utskriftsteknik:	Epson Email Print, Epson Remote Print, Apple AirPrint, Epson Connect, Epson iPrint
PictBridge:	Ja
Maximalt antal kopior:	99 kopior
Dubbelsidig kopiering:	Ja
Dubbelsidig faxning:	Ja
Automatisk dokumentmatare (ADF):	Ja
Skrivarhantering:	Auto Photo Correction, ICM
Typ av minneskort:	CF, SD, SDHC, SDXC
Produktens färg:	Black, Blue
Kontrolltyp:	Röra
Inbyggd kortläsare:	Ja
Mac-operativsystem som stöds:	Mac OS X 10.10 Yosemite
Utskrift:	Färgutskrift
Dubbelsidig utskrift:	Ja
Kopiering:	Färgkopiering
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Temperatur vid drift:	10 - 35 ° C
Temperaturintervall (förvaring):	-20 - 40 ° C
Intervall för relativ operativ luftfuktighet:	20 - 80 %
Fuktighet (förvaring):	5 - 85 %
Hållbarhetscertifiering:	RoHS, ENERGY STAR
AC-inspänning:	100 - 240 V
Nätverksansluten (Ethernet):	Ja
Skanningstyp:	Flatbädds- och ADF-scanner
Växelström Frekvens:	50 - 60 hz
Displaytyp:	LCD
Ljudnivå Lc IEC:	43 dB
Antal USB 2.0 anslutningar:	1
USB-port:	Ja
Medföljande programvara:	Epson printer drivers, Epson Print CD, Epson Scan, Epson Easy Photo Scan, User Guide, PC-Fax 8
Strömförbrukning i avslaget läge:	0.3 W
Positionering på marknaden:	Hem och kontor
Direktutskrift:	Ja
Drivrutiner medföljer:	Ja
Utskriftsteknologi:	Bläckstråleskrivare
Utskriftshastighet (Svart, normalkvalitet, A4/US Brev):	- ppm
Utskriftshastighet (färg, normal kvalitet, A4/US Letter):	11 ppm
Driftcykel per månad:	- sidor per månad
Språk för sidbeskrivning:	ESC P, ESC/P-R
Total inmatningskapacitet:	100 ark
Pappersinmatningstyp:	Pappersfack
Total utmatningskapacitet:	30 ark
Högsta ISO A-seriestorlek:	A4
Pappersfackets typ av media:	Glossy paper, Iron-On Transfers, Matte paper, Photo paper, Semi-glossy paper
ISO A-serie storlek (A0...A9):	A4, A5, A6
ISO B-seriestorlekar (B0 ... B9):	B5
Maximal skannerupplösning:	9600 x 9600 DPI
Ingång, färgdjup:	48 bit
Optisk skanningsupplösning:	4800 x 4800 DPI
Skanning:	Färgscanning
Kopieringshastighet (normalkvalitet, svart, A4):	11 kopior per minut
Kopieringshastighet (färg, normalkvalitet, A4):	8.1 kopior per minut
Storleksändring kopieringsmaskin:	25 - 400 %
Kuvertstorlek:	10
Strömförbrukning (genomsnittligt operativt):	13 W
DVD/CD utskrift:	Ja
Kopiering utan dator:	Ja
Utgång, färgdjup:	24 bit
Skanningsteknik:	CIS
Skanning till:	Cloud
Skrivarfäger:	Black, Cyan, Magenta, Photo black, Yellow
Patron (er) som ingår:	Ja
Gråskalenivå:	16
Dubbelsidig skanning:	Ja
Kapacitet för automatisk dokumentmatare:	30 ark
Fax sändningshastighet:	3 sek/sida
Högsta antal kortnummer:	100
Foto-pappersstorlekar (imperial):	4x6, 5x7, 8x10, 8.5x11 "
Dubbelsidig utskriftshastighet (svart, normal kvalitet, A4/US Brev):	5.4 ppm
Dubbelsidig utskriftshastighet (färg, normal kvalitet, A4/US Brev):	4.4 ppm
