At ErgoAV, our goal is to add value to your AV experience by providing the highest
quality products and services in the industry. We offer a 5-year warranty. If you have
any questions or concerns, please contact us.
ERMTL7
Thank you for choosing ErgoAV!
Rev00
Large Extend & Tilt TV Mount
Instruction Manual
English 02-15 Español 30 a 43 Français 16 à 29
DANGER: Please carefully read all instructions before attempting installation. If you DO NOT
understand the instructions or have any questions or concerns, please call technical support or
email customer service.
CAUTION: Avoid the risk of personal injury and property damage!
WARNING: All fasteners must be firmly tightened!
• This mount can only be installed on wood studs, concrete and concrete block walls. DO NOT
install on drywall alone.
• The wall must be capable of supporting four times the weight of the TV and mount combined.
• This product contains small parts that may pose a choking hazard.
• DO NOT use this product for any purpose that is NOT explicitly specified in this manual. DO
NOT exceed the maximum weight capacity. We are not liable for damage or injury caused by
incorrect assembly, improper mounting, or inappropriate use.
• Use this mounting system only for its intended purpose as described in these instructions. DO
NOT use attachments not recommended by the manufacturer.
• DO NOT use outdoors.
• Route cords and cables properly to avoid mechanical damage.
SAVE THESE INSTRUCTIONS
2
Important
Safety
Information
BEFORE GETTING STARTED, LET'S MAKE SURE THIS MOUNT
IS COMPATIBLE
Check VESA
Pattern
Compatibility
Check Max
Load
Verify
Wall Type
Tools Needed
(not included)
DO NOT exceed the Max Load. Use with products heavier than the Max
Load may result in failure of the mount and its accessories, causing
possible damage and/or injury.
WARNING
If your TV weighs more, this mount is NOT compatible.
Maximum/Minimum:
600 x 400mm (23.6 x 15.7˜)
200 x 100mm (7.9 x 3.9˜)
Compatible VESA Patterns:
200 x 100mm
200 x 200mm
200 x 300mm
If this mount is not compatible, please contact product support.
1
3
4
5
200 x 400mm
300 x 200mm
300 x 300mm
300 x 400mm
400 x 200mm
400 x 300mm
400 x 400mm
500 x 400mm
600 x 400mm
150 lbs
(68kg)
Max:
15.7˜
400mm
Max:
23.6˜
600mm
For Wood Stud Walls
7/32˜ (5.5mm)
Wood Drill Bit
Stud Finder Awl
3/8˜ (10mm)
Concrete Drill Bit
Hammer
For Concrete and Concrete Block Walls
Electric
Drill Pencil
Phillips
Screwdriver
Tape
Measure Level
1/2˜ (13mm)
Socket Wrench
Perfect
Concrete and Concrete
Block Walls
Wood Studs
(with Drywall)
16˜ (406mm)
24˜ (610mm)
Perfect
?
Unsure?
Contact us.
02 03 04 05 06 07 08 09 10 11 12 13 14 15
16 17 18 19 20 21 22 23 24 25 26 27 28 29
30 31 32 33 34 35 36 37 38 39 40 41 42 43
