Sida 1/20

User Manual

Off Board Undermount

Rangehood

INLU92BG - HOOD

INLEM3 / INLRCM3 - MOTOR

Content

1…………………………………..………………………………Safety instructions

2…………………………………..………………………………Installation

3…………………………………..………………………………Start using your Rangehood

4…………………………………..………………………………Troubleshooting

5…………………………………..………………………………Maintenance and cleaning

6…………………………………..………………………………Environment protection

SAFETY INSTRUCTIONS

This manual explains the proper installation and use of your Rangehood, please read

it carefully before using even if you are familiar with the product. The manual should

be keptin a safe place for future reference.

These instructions shall also be available in an alternative format, e.g. on a website or

on request from the user in a spec sheet format.

Things to never do:

● Do not try to use the Rangehood

without the grease filters or if the filters

are excessively greasy!

●Do not install above a cooker with a

high level grill.

●Do not leave frying pans unattended

during use because overheated fats or

oils might catch fire.

●Never leave naked flames under the

Rangehood.

●If the Rangehood is damaged, do not

attempt to use.

●Do not flambé under the Rangehood.

●CAUTION: Accessible parts may

become hot when used with cooking

appliances.

●The minimum distance between the

supporting surface for the cooking

vessels on the hob and the lowest part

of the Rangehood. (When the

Rangehood is located above a gas

appliance, this distance shall be at

least 65 cm)

●The air must not be discharged into a

flue that is used for exhausting fumes

from appliances burning gas or other

fuels.

Things to always do:

●Important! Always switch off the

electricity supply at the mains during

installation and maintenance such as

light bulb replacement.

●The Rangehood must be installed in

accordance with the installation

instructions and all measurements

followed.

●All installation work must be carried out

by a competent person or qualified

electrician.

●Please dispose of the packing material

carefully. Children are vulnerable to it.

● Pay attention to the sharp edges

inside the Rangehood especially

during installation and cleaning.

●When the Rangehood is located above

a gas appliance, the minimum

distance between the supporting

surface for the cooking vessels on the

hob and the lowest part of the

Rangehood that distance must be:

Gas cookers: 75 cm

Electric cookers: 65 cm

Coal or oil cookers: 75 cm

●Make sure the ducting has no bends

sharper than 90 degrees as this will

reduce the efficiency of the

Rangehood.

●Warning: Failure to install the screws or

fixing device in accordance with these

instructions may result in electrical

hazards

●Warning: Before obtaining access to

terminals, all supply circuits must be

disconnected.

Things to always do:

●Always put lids on pots and pans when

cooking on a gas cooker.

●When in extraction mode, air in the

room is being removed by the

Rangehood. Please make sure that

proper ventilation measures are being

observed. The Rangehood removes

odours from room but not steam.

●Rangehood is for domestic use only.

●If the supply cord is damaged, it must

be replaced by the manufacturer, its

service agent or similarly qualified

persons in order to avoid a hazard.
