Sida 1/2
Gas Spring
L Shape WrenchGas Spring Cover
8 Hexagonal Socket Bolts 2 small bolts and 2 screw covers
Back rest Seat
Model A Mechanism
Model B Mechanism Five Star Base
NOTES
※ ※
1. Please avoid the fire, direct sunlight and
wet environment.
2. Please do not put the chair on a high or
unstable place, in case falling down.
3. Please put the chair on a flat ground.
4. Please pay attention to your kids when
they are climbing the chair.
5. Please pay attention to the natural loosen
of the bolts after long-term using, avoid
sharp things scratch the chair.
6. Please avoid excessive tilt using in case
falling down.
MANUAL
Thanks for buying our product.
Please read this manual carefully
before installation and use as the
manual said. In order to refer more
information please take care of the
manual.
Model A
Model B
5 Wheels
2 Recliner Covers
Mounting diagram for model B
Mounting diagram for model A
Picture 1
Picture 2
STEP
1
Put the back rest and seat together
Put the back rest and seat together as the
picture 1. Please pay attention to the red
marked place ( left and right sides) which
need aim at the bolts holes.
STEP
4
Install the mechanism
Use the bolts to lock the mechanism
and seat together, and make sure the
bolts are screwed in tight.
Install the handles and push them
to the bottom
STEP
4
Install the mechanism
Use the bolts to lock the mechanism
and seat together, and make sure the
bolts are screwed in tight.
STEP
5
Install the wheel
STEP
6
Install the gas spring
STEP
7
Put on the gas spring cover
STEP
2
Lock the back rest and seat
Lock the 4 bolts on the left and right side
as the picture step by step.
(Please remove the bolts that are pre-mounted
on the backrest; two bolts are located on each
side of the backrest.Place the backrest on the
seat. Begin at the right side where the tilting
handle is located.Screw both bolts on the right
side half way in and then screw in the two bolts
on the left side. Now tighten the bolts on both
sides)
STEP
3
Install the recliner covers
Attach the lower snap button first. Lock the screw into the hole
on the recliner cover, and then attach the screw cover on it.
Model A
Model B
STEP
8 Put the chair body on the gas spring
Aim at the top of gas spring and the hole of mechanism,
then put the chair body down.
Usage & Safety Instructions
Sit in the center of the chair,
with your back to the backrest.
Do not sit at the front edge of
the chair.
Do not push the chair
aroundwhen a person
is sitting in it.
Do not place all your
weight on
the backrest only.
Do not place your hand
orfingers near the
recline mechanics.
Do not push down
on thebackrest when
a person is reclined.
Do not stand on the chair. Do not use the chair with more
than one person
