A03-A04

Electronic level controls with probes for conductive liquids

Electronic level controls with probes to control and monitor the level of conductive liquids. Suitable to control au-

toclave pumps, steam generator pumps, tanks filling and emptying etc.

1 SENSITIVITY - 2 MANUAL RESET - 3 ALARMS

mounting on 35 mm rail EN 50022-3 DIN 46277-3

ELECTRICAL FEATURES

Voltage between the electrodes: 8 Va.c.

Adjustable detection range from 2 to 20 k W.

Cable section 1mm

2

, maximal cable length 800 mt, insulation 600 Va.c.

Insulation resistance: 100 M V.

Dielectric strength 1.500 Va.c. in 1 min.

Output connection through electromagnetic SPDT relay.

Consumption: 4VA.

Level increase:

1-2 opens

1-4 closes

Level decrease:

1-4 opens

1-2 closes

HOMOLOGATION AND STANDARDS

Conformity with CEI-EN 60947-5-1 standards.

INSTALLATION

Fixing by clip-on to 35 mm rail EN 50022-3, DIN 46277-3 or using plates, supplied for surface installation.

Dimensions (mm)

20

60

45

905

1936355

33211

POWER SUPPLYCONTACT

RATING

250Vac

OPERATING

TEMPERATURE

PROTECTION

DEGREE

AVAILABILITY

Electronic level controls

A03F24 Vac5A - AC12-10 ÷ 50 °CIP20in stock

A03M230 Vac5A - AC12-10 ÷ 50 °CIP20in stock

Shutdown level controls with manual reset

A04F24 Vac5A - AC12-10 ÷ 50 °CIP20in stock

A04M230 Vac5A - AC12-10 ÷ 50 °CIP20in stock
