M100 / M200 Series
Quick start guide
© 2017 FLIR Systems, Inc.
76001-2Document number:
10-2017
Date:
English (en-US)
*M200 Series cameras only
320 x 240 resolution thermal
sensor, with H264-encoded IP
digital video stream
Automatic window heater
(de-ice / de-mist)
+110°/-90° tilt assembly
360° pan assembly*
Mount the camera, and make power & network connections
Choose a mounting orientation for the camera
Make system connections
1Connect the power and network cables
3
Using the supplied mounting template, seal
and fasteners, mount the camera to the vessel
2
Ball up Ball down
• Red: +ve (12 / 24 V)
• Black (thick): -ve (0 V)
• Black (thin): Drain / Ground
Network
(RayNet)
*RayNet-to-RJ45
adapter
Power & drain
Your thermal camera has a single RayNet network connector. This connects the
camera to your vessel’s wider IP network. This could be an existing third-party
Ethernet network, or a dedicated Raymarine® RayNet network. For more basic setups,
the camera can be connected directly to a laptop or PC.
The details of the network connections between the camera, video display, control
unit, and the rest of your installation depend on:
• how you want to control the camera (for example, with a web browser, a
Raymarine® LightHouse™ multifunction display (MFD)
†
, a JCU controller, or a
combination);
• how you want to view the camera’s IP video feed (for example, with an analog video
monitor (connected via an IP video decoder), a Raymarine® LightHouse™ multifunc-
tion display (MFD)
†
, a web browser, or a combination);
• the equipment already installed on your vessel (for example, network switches with
free ports, analog video monitors, or other cameras).
The illustrations to the right show two examples of possible system layouts:
A — a basic system with a single camera directly connected to a web browser, via a
laptop computer or PC.
B — a more complex multi-camera, multi-display, multi-JCU system.
RayNet
RayNet RayNet
RayNet
Analog video monitor
RJ45
(Ethernet)
Composite
video
IP video decoder
JCU-3 JCU-3
RJ45
(Ethernet)
RayNet
network switches
A
B
Laptop computer or PC
Laptop computer or PC
RJ45
(Ethernet)
RayNet
Note: Power connections are not shown. Each device requires either a dedicated power
connection, or a Power over Ethernet (PoE) supply.
RayNet
Note: Power connections are not shown. Each device requires its own power connection.
† LightHouse™ 3, or LightHouse™ 2 Release 19
*optional
This document is a subset of the complete documentation available for your
product. Visit the FLIR website to download the complete and latest
documentation available for your product, in your preferred language.
IMPORTANT
http://www.flir.com/marine/support
M100 / M200 Series cameras support DHCP and
UPnP to simplify the process of finding the camera
on your network, and connecting to it using a Web
browser.
To access the camera web page from a Windows
PC or laptop, double-click the camera in the
Windows Explorer “Network” folder. Alternatively,
type the camera’s IP address into your Web
browser’s address bar. Then, log in with User Name
“user”, and the default Password, “user”.
Note: See the documentation provided with your
camera for more information.
Connecting to the camera and controlling with a Web browser
Thermal imaging (also known as infrared)
cameras enable you to see clearly in
low-light and no-light conditions. For
example, a thermal camera can help you
navigate at night or identify obstacles in
areas of low visibility or even total
darkness.
Your M100 / M200-Series thermal camera
is a network device that communicates
over an Ethernet network using Internet
Protocol (IP).
You can use various types of IP-networked
device to interact with the camera’s web
interface, such as a laptop, PC, tablet or
smartphone.
Using a Web browser, you can:
• Control the camera:
– Pan* and tilt the camera
– Zoom the video image (digital)
– Return the camera to its “home”
(default) position
– Set the camera “home” position
– Activate and adjust surveillance scan
– Manually control the de-ice/de-mist
window heater
• Adjust the camera image:
– Color palette
– Scene presets.
*M200-Series cameras only
On the page:Live Video
• Click and drag the virtual joystick up or down
to tilt the camera.
• Click and drag the virtual joystick left or right to
pan the camera (M200 Series only).
• Click and hold the zoom-in
button to reduce the field of view.
The current zoom level (between x1.0 and x4.0) is
shown at the bottom-right of the thermal image.
• Click and hold the zoom-out
button to increase the field of view.
On the page:Live Video
• Click the Toggle Palette button to
cycle through 4 different color palettes:
WhiteHot RedHot Fusion FireIce; ; ; .
• Click the button to toggle the Polarity
image polarity: ; BlackHot RedHot-
Inverse Fusion Inverse FireIce Inverse; ; .
• Click the Toggle Scene Preset button
to cycle through 4 presets: ; Day Night;
Docking High Contrast; .
Depending on the time of day, weather, and other
conditions, one scene preset may produce a
clearer thermal image than the others.
3Adjust the thermal image
2Pan, tilt, and zoom the
thermal image
1Connect to the camera web page
and log in
